Geo Prizm II (1992-1997) snroof pos motor ctrl ign slide close slide open tilt down snroof pos Wiring diagram
This page shows the only wiring diagram for the component.snroof pos motor ctrl ign slide close slide open tilt down snroof pos, which is found in the car Geo Prizm II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram snroof pos motor ctrl ign slide close slide open tilt down snroof pos (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 MOTOR CTRL TILT UP
ACCESSORY FUSE
ACCESSORY POWER RELAY
AUDIO ALARM MODULE
BLK WIRE
BLU WIRE
GAUGE FUSE
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN AND START
J/B 1 (BEHIND LEFT KICK PANEL)
J/B 3 (BEHIND CENTER OF I/P)
PNK WIRE
POWER WINDOWS SYSTEM
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY BLOCK CASSETTE
SLIDE OPEN SLIDE CLOSE
SNROOF POS MOTOR CTRL IGN SLIDE CLOSE SLIDE OPEN TILT DOWN SNROOF POS
SUNROOF ACTUATOR ASSEMBLY (FRONT CENTER OF ROOF HEADLINER)
SUNROOF CONTROL MODULE (FRONT CENTER OF ROOF HEADLINER)
SUNROOF LIMIT SWITCH NO 1
SUNROOF LIMIT SWITCH NO 2
SUNROOF MOTOR
SUNROOF SWITCH
SUNROOF SWITCH ASSEMBLY
TILT DOWN
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
