Geo Prizm II (1992-1997) right front wheel speed sensor conn break out) Wiring diagram
This page shows the only wiring diagram for the component.right front wheel speed sensor conn break out), which is found in the car Geo Prizm II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front wheel speed sensor conn break out) (1 of 1)
1.6L
1.8L
ABS ENABLE RELAY
AUDIO ALARM MODULE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/RED WIRE
BREAK- OUT)
BRN WIRE
CENTER SENSOR ASSEMBLY
CENTER SENSOR ASSEMBLY (I/P HARN 1,
CIG/ RADIO FUSE
CONN BREAK OUT)
DISTRIBUTOR
ELECTRONIC BRAKE CONTROL MODULE
FROM
FROM ACCESSORY FUSE (J/B 1) (SCHEMATIC 5 OF 6)
FROM J/B 3
FUEL INJECTOR NO 1
FUEL INJECTOR NO 2 FUEL INJECTOR NO 4 FUEL INJECTOR NO 3
GRY WIRE
IGN FUSE
IGNITER
IGNITER (1.6L-VIN 6 1995 ONLY)
IGNITION COIL NOISE SUPPRESSOR CONDENSOR
IGNITION SWITCH
INSTRUMENT CLUSTER
J/B 1 (BEHIND LEFT KICK PANEL)
J/B 3 (BEHIND CENTER OF I/P)
LOCK
ORG/RED WIRE
POWER MIRROR SWITCH
RADIO CONN BREAK OUT)
RED/WHT WIRE
RIGHT FRONT WHEEL SPEED SENSOR CONN BREAK OUT)
SHIFTLOCK CONTROL MODULE
TO CIGAR LIGHTER (SCHEMATIC 5 OF 6)
TO CRUISE CONTROL DIODE (SCHEMATIC 6 OF 6)
TO EFI F-HTR RELAY (FUSE, RELAY BOX) (SCHEMATIC 1 OF 6)
TO GAUGE FUSE (J/B 1) (SCHEMATIC 3 OF 6)
W/ ABS ONLY
WHT WIRE
Go to component -> Power distribution circuit (2 of 6) -> RIGHT FRONT WHEEL SPEED SENSOR CONN BREAK OUT)
