Geo Prizm II (1992-1997) relay block cassette Wiring diagrams
This page contains all the electrical diagrams for the component. relay block cassette, in which he is found in the car Geo Prizm II (1992-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram relay block cassette (1 of 2)
1996 ONLY
ACCESSORY POWER RELAY
AUDIO ALARM MODULE
BLK WIRE
BREAKOUT)
BRN WIRE
CENTER HIGH MOUNTED STOPLAMP
CENTER SENSOR ASSEMBLY
CIGAR LIGHTER
COMBINATION SWITCH
DAYTIME RUNNING LAMPS CONTROL
FROM J/B 2
FROM J/B 2 (DIAGRAM 3 OF 4)
FROM J/B 3 (DIAGRAM 1 OF 4) FROM J/B 3
FUEL PUMP NOISE SUPRESSOR
FUEL SENDER ASSEMBLY
INSTRUMENT CLUSTER
J/B 1 CENTER SENSOR ASSEMBLY
J/C 1
J/C 3
LEFT BACKUP LAMP
LEFT FRONT POWER DOOR LOCK ACTUATOR
LEFT LICENSE PLATE LAMP
LEFT REAR COMBINATION LAMP
LIGHT/ TURN SIGNAL SWITCH
LIGHT/TURN SIGNAL SWITCH
MODULE GROUND
NCA WIRE
OUT
POWER DOOR LOCK CONTROL MODULE
PUMP FUEL
RADIO
RELAY BLOCK CASSETTE
RIGHT BACKUP LAMP
RIGHT FRONT POWER DOOR LOCK ACTUATOR
RIGHT LICENSE PLATE LAMP
RIGHT POWER DOOR LOCK SWITCH CONNECTOR
RIGHT REAR COMBINATION LAMP
SIDE MARKER LAMP
SUNROOF ACTUATOR ASSEMBLY
SUNROOF CONTROL MODULE
SUNROOF LIMIT SWITCH NO 1
SUNROOF LIMIT SWITCH NO 2
SUNROOF MOTOR
SUNROOF SWITCH ASSEMBLY
SUNROOF SWITCH MAP LAMP
TAIL/ STOP LAMP
TAIL/ TURN LAMP
TURN/ HAZARD FLASHER
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WASHER SWITCH
Go to component -> Ground distribution circuit (4 of 4) -> RELAY BLOCK CASSETTE
Wiring diagram relay block cassette (2 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 MOTOR CTRL TILT UP
ACCESSORY FUSE
ACCESSORY POWER RELAY
AUDIO ALARM MODULE
BLK WIRE
BLU WIRE
GAUGE FUSE
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN AND START
J/B 1 (BEHIND LEFT KICK PANEL)
J/B 3 (BEHIND CENTER OF I/P)
PNK WIRE
POWER WINDOWS SYSTEM
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY BLOCK CASSETTE
SLIDE OPEN SLIDE CLOSE
SNROOF POS MOTOR CTRL IGN SLIDE CLOSE SLIDE OPEN TILT DOWN SNROOF POS
SUNROOF ACTUATOR ASSEMBLY (FRONT CENTER OF ROOF HEADLINER)
SUNROOF CONTROL MODULE (FRONT CENTER OF ROOF HEADLINER)
SUNROOF LIMIT SWITCH NO 1
SUNROOF LIMIT SWITCH NO 2
SUNROOF MOTOR
SUNROOF SWITCH
SUNROOF SWITCH ASSEMBLY
TILT DOWN
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Power top/sunroof circuits -> RELAY BLOCK CASSETTE
