Geo Prizm II (1992-1997) rear defogger indicator Wiring diagrams

1995 ONLY AUDIO ALARM MODULE (ATTACHED TO JUNCTION BLOCK 1) BLK WIRE BLU WIRE DEFOG- I/UP FUSE DEFOGGER FUSIBLE LINK DEFOGGER RELAY DEFOGGER RELAY CONTROL GAUGE FUSE GROUND HOT AT ALL TIMES HOT IN ON AND START IGNITION POWER INSTRUMENT CLUSTER JUNCTION BLOCK 1 (LOWER LEFT SHROUD BEHIND KICK PANEL) JUNCTION BLOCK 3 (BEHIND CENTER OF I/P) JUNCTION CONNECTOR 1 (ATTACHED TO RIGHT I/P SUPPORT BRACE) JUNCTION CONNECTOR 3 (BEHIND CENTER OF I/P) REAR DEFOGGER REAR DEFOGGER INDICATOR REAR DEFOGGER NOISE FILTER (BEHIND LEFT KICK PANEL) REAR DEFOGGER SWITCH RED/BLU WIRE TIMER/ENABLE DISABLE SIGNAL WHT WIRE WHT/BLK WIRE

11 9 (1995 1.6L) (1995 1.8L, 1996 1.6L/1.8L) 17 23 (1996) (1995) BRAKE IND CTRL 1995 ONLY 1996 ONLY ABS ACTIVE INDICATOR ABS INDICATOR AIR BAG INDICATOR ANTI-LOCK BRAKES SYSTEM AUDIO ALARM MODULE BLK WIRE BLK/ORG WIRE BLK/YEL WIRE BLU/YEL WIRE BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR) BRAKE INDICATOR BRN WIRE BULB CHECK RELAY CHARGE INDICATOR CRUISE CONTROL MODULE (BELOW RADIO) CRUISE CONTROL SYSTEM STARTING/CHARGING SYSTEM CRUISE INDICATOR DATA LINK CONNECTOR (PARTIAL) (ON LEFT STRUT TOWER) DAYTIME RUNNING LAMPS CONTROL MODULE (LEFT OF BRAKE PEDAL) BRAKE IND CTRL DAYTIME RUNNING LAMPS INDICATOR DOOR OPEN INDICATOR ENGINE CONTROLS SYSTEM DEFOGGERS SYSTEM ENGINE COOLANT TEMPERATURE GAGE ENGINE COOLANT TEMPERATURE SENDING UNIT (IN THERMOSTAT HOUSING) ENGINE SPEED OUT FROM RIGHT REAR ENGINE COMPT BULKHEAD GROMMET) FUEL GAGE FUEL GAGE SENDING UNIT FUEL SENDER ASSEMBLY (IN FUEL TANK) GAUGE FUSE GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE HIGH BEAM INDICATOR HOT IN ON AND START ILLUMINATION LAMP (4 BULBS) INSTRUMENT CLUSTER INTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM (DRL) J/B 1 (BEHIND LEFT KICK PANEL) J/B 3 (BEHIND CENTER OF I/P) J/C 1 (BEHIND CENTER OF I/P, ATTACHED TO RIGHT I/P SUPPORT BRACE) J/C 3 (ATTACHED TO J/B 3) LEFT TURN INDICATOR LT GRN WIRE MALFUNCTION INDICATOR LAMP O/D OFF INDICATOR (1.8L-VIN 8 W/ A/T) OIL PRESSURE INDICATOR OIL PRESSURE SWITCH (IN RIGHT FRONT OF ENGINE BLOCK) P BRAKE SIG PARKING BRAKE SWITCH (IN CENTER CONSOLE) PNK WIRE PPL/WHT WIRE PWR REAR DEFOGGER INDICATOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT TURN INDICATOR SEAT BELT INDICATOR SPEEDOMETER STARTING/ CHARGING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM TACHOMETER (OPTIONAL) VEHICLE SPEED SENSOR (RIGHT REAR OF TRANSAXLE) VSS OUT VSS IN WARNING SYSTEM WARNING SYSTEMS TRANSMISSIONS SYSTEM WHT WIRE WHT/BLK WIRE WHT/GRN WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
