Geo Prizm II (1992-1997) park/neutral position switch (left side of Wiring diagram
This page shows the only wiring diagram for the component.park/neutral position switch (left side of, which is found in the car Geo Prizm II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park/neutral position switch (left side of (1 of 1)
1995 1.6L
1995 1.8L 1996 1.6L, 1.8L
ALT FUSE
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BREAK- OUT)
CIRCUIT OPENING RELAY (NEAR RADIO) BREAK OUT)
CRANK SIGNAL
ENGINE CONTROL MODULE (1.6L/VIN 6) (FRONT OF CENTER CONSOLE)
FROM J/B 3
FUSE
FUSE, RELAY BOX (LEFT FRONT OF ENGINE COMPT)
FUSIBLE LINK
GRN WIRE
IGNITION SWITCH
INSTRUMENT CLUSTER BULB CHECK RELAY
J/B 1 (BEHIND LEFT KICK PANEL)
J/B 2 (BEHIND RIGHT KICK PANEL)
LOCK
PARK/NEUTRAL POSITION SWITCH (LEFT SIDE OF
POWERTRAIN CONTROL MODULE (1.8L/VIN 8) (FRONT OF CENTER CONSOLE)
S249 (1.6L) S201 (1.8L)
STARTER
STARTER RELAY (RELAY BLOCK CASSETTE)
TRANSAXLE
WHT WIRE
Go to component -> Starting circuit, a/t -> PARK/NEUTRAL POSITION SWITCH (LEFT SIDE OF
