Geo Prizm II (1992-1997) left backup lamp conn break out) Wiring diagram
This page shows the only wiring diagram for the component.left backup lamp conn break out), which is found in the car Geo Prizm II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left backup lamp conn break out) (1 of 1)
A/T
AUDIO ALARM MODULE
BACKUP LAMP SWITCH (TOP OF TRANSAXLE)
GAUGE FUSE
HOT IN ON AND START
J/B 1 (BEHIND LEFT KICK PANEL)
J/B 3 (BEHIND CENTER OF I/P)
LEFT BACKUP LAMP
LEFT BACKUP LAMP CONN BREAK OUT)
M/T
PARK/ NEUTRAL POSITION SWITCH (LEFT SIDE OF TRANSAXLE)
POS SIG
POWERTRAIN CONTROL MODULE (1.8L ONLY) (FRONT OF CENTER CONSOLE)
RED/BLK WIRE
RED/BLU WIRE
RIGHT BACKUP LAMP
WHT/BLK WIRE
Go to component -> Backup lamps circuit -> LEFT BACKUP LAMP CONN BREAK OUT)
