Geo Prizm II (1992-1997) j/b 1 center sensor assembly Wiring diagram
This page shows the only wiring diagram for the component.j/b 1 center sensor assembly, which is found in the car Geo Prizm II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram j/b 1 center sensor assembly (1 of 1)
1996 ONLY
ACCESSORY POWER RELAY
AUDIO ALARM MODULE
BLK WIRE
BREAKOUT)
BRN WIRE
CENTER HIGH MOUNTED STOPLAMP
CENTER SENSOR ASSEMBLY
CIGAR LIGHTER
COMBINATION SWITCH
DAYTIME RUNNING LAMPS CONTROL
FROM J/B 2
FROM J/B 2 (DIAGRAM 3 OF 4)
FROM J/B 3 (DIAGRAM 1 OF 4) FROM J/B 3
FUEL PUMP NOISE SUPRESSOR
FUEL SENDER ASSEMBLY
INSTRUMENT CLUSTER
J/B 1 CENTER SENSOR ASSEMBLY
J/C 1
J/C 3
LEFT BACKUP LAMP
LEFT FRONT POWER DOOR LOCK ACTUATOR
LEFT LICENSE PLATE LAMP
LEFT REAR COMBINATION LAMP
LIGHT/ TURN SIGNAL SWITCH
LIGHT/TURN SIGNAL SWITCH
MODULE GROUND
NCA WIRE
OUT
POWER DOOR LOCK CONTROL MODULE
PUMP FUEL
RADIO
RELAY BLOCK CASSETTE
RIGHT BACKUP LAMP
RIGHT FRONT POWER DOOR LOCK ACTUATOR
RIGHT LICENSE PLATE LAMP
RIGHT POWER DOOR LOCK SWITCH CONNECTOR
RIGHT REAR COMBINATION LAMP
SIDE MARKER LAMP
SUNROOF ACTUATOR ASSEMBLY
SUNROOF CONTROL MODULE
SUNROOF LIMIT SWITCH NO 1
SUNROOF LIMIT SWITCH NO 2
SUNROOF MOTOR
SUNROOF SWITCH ASSEMBLY
SUNROOF SWITCH MAP LAMP
TAIL/ STOP LAMP
TAIL/ TURN LAMP
TURN/ HAZARD FLASHER
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WASHER SWITCH
