Geo Prizm II (1992-1997) intermittent controller Wiring diagram
This page shows the only wiring diagram for the component.intermittent controller, which is found in the car Geo Prizm II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intermittent controller (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMBINATION SWITCH
HOT IN ON AND START
INTERMITTENT CONTROLLER
J/B 1 (ABOVE LEFT KICK PANEL)
J/C 1 (ATTACHED TO RIGHT I/P SUPPORT BRACE)
LO PARK WIPER MOTOR
OFF
OFF HI HI INT LO LO
OFF OFF HI INT INT LO
RED/BLU WIRE
RUN WIRE
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WASHER PUMP (ATTACHED TO WASHER FLUID RESERVOIR)
WINDSHIELD WIPER MOTOR (RIGHT REAR OF ENGINE COMPARTMENT) HIGH
WIP FUSE
WIPER SWITCH
Go to component -> Interval wiper/washer circuit -> INTERMITTENT CONTROLLER
