Geo Prizm II (1992-1997) instrument cluster bulb check relay Wiring diagrams
This page contains all the electrical diagrams for the component. instrument cluster bulb check relay, in which he is found in the car Geo Prizm II (1992-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram instrument cluster bulb check relay (1 of 2)
1995 1.6L
1995 1.8L 1996 1.6L, 1.8L
ALT FUSE
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BREAK- OUT)
CIRCUIT OPENING RELAY (NEAR RADIO) BREAK OUT)
CRANK SIGNAL
ENGINE CONTROL MODULE (1.6L/VIN 6) (FRONT OF CENTER CONSOLE)
FROM J/B 3
FUSE
FUSE, RELAY BOX (LEFT FRONT OF ENGINE COMPT)
FUSIBLE LINK
GRN WIRE
IGNITION SWITCH
INSTRUMENT CLUSTER BULB CHECK RELAY
J/B 1 (BEHIND LEFT KICK PANEL)
J/B 2 (BEHIND RIGHT KICK PANEL)
LOCK
PARK/NEUTRAL POSITION SWITCH (LEFT SIDE OF
POWERTRAIN CONTROL MODULE (1.8L/VIN 8) (FRONT OF CENTER CONSOLE)
S249 (1.6L) S201 (1.8L)
STARTER
STARTER RELAY (RELAY BLOCK CASSETTE)
TRANSAXLE
WHT WIRE
Go to component -> Starting circuit, a/t -> INSTRUMENT CLUSTER BULB CHECK RELAY
Wiring diagram instrument cluster bulb check relay (2 of 2)
1995 1.6L
1995 1.8L 1996 1.6L, 1.8L
ALT FUSE
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BREAK- OUT)
CIRCUIT OPENING RELAY (NEAR RADIO) BREAK OUT)
CLUTCH PEDAL POSITION SWITCH (ON BRACKET, ABOVE CLUTCH PEDAL)
CRANK SIGNAL
ENGINE CONTROL MODULE (1.6L/VIN 6) (FRONT OF CENTER CONSOLE)
FROM J/B 3
FUSE
FUSE, RELAY BOX (LEFT FRONT OF ENGINE COMPT)
FUSIBLE LINK
GRN WIRE
IGNITION SWITCH
ILLUMINATION CONTROLLER CONNECTOR BREAK OUT)
INSTRUMENT CLUSTER BULB CHECK RELAY
J/B 1 (BEHIND LEFT KICK PANEL)
J/B 2 (BEHIND RIGHT KICK PANEL)
LOCK
POWERTRAIN CONTROL MODULE (1.8L/VIN 8) (FRONT OF CENTER CONSOLE)
STARTER
STARTER RELAY (RELAY BLOCK CASSETTE)
WHT WIRE
Go to component -> Starting circuit, m/t -> INSTRUMENT CLUSTER BULB CHECK RELAY
