Geo Prizm II (1992-1997) ignition signal a/c sv valve Wiring diagram

1995 VFTC A/C CUTOUT CNTRL IGNITION POWER MIL CONTROL A/C ON SIGNAL VSS INPUT ELI SIGNAL A/T A/T ONLY AIR CONDITIIONING SYSTEM (A/C AMPLIFIER) BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN OR BLK/WHT WIRE BRN WIRE COR CONTROL CRANK SIGNAL IGN FAIL SAFE SIG CRANK ANGLE HIGH CSI HIGH DATA LINK CONNECTOR (LEFT REAR SIDE OF ENGINE COMPARTMENT) DEFOG- I/UP FUSE DISTRIBUTOR DISTRIBUTOR ASSEMBLY ELECTRICAL LOAD IDLE-UP DIODE (BEHIND LEFT SIDE OF INSTRUMENT CLUSTER) ENGINE CONTROL MODULE (ECM) (BEHIND FRONT CONSOLE UNDER BLOWER CASE) GRD OR P,N INPUT EGR SV VALVE CRANK ANGLE LOW CPI LOW GRN WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT WITH HEADLIGHT SWITCH IN HEAD OR PARK HOT WITH REAR DEFOGGGER SWITCH ON IAC VALVE CLOSE IAC VALVE OPEN IGNITER IGNITION COIL IGNITION SIGNAL A/C SV VALVE IGNITION SWITCH INJ 1, 3 CNTRL GROUND INJ 2, 4 CNTRL GROUND INJECTOR 1 INJECTOR 2 INJECTOR 3 INJECTOR 4 INSTRUMENT CLUSTER SYSTEM JUNCTION BLOCK 1 KNOCK SENSOR CONNECTOR (NOT USED) LOCK LT GRN WIRE LT GRN/RED WIRE M/T M/T ONLY MEMORY POWER NCA WIRE PPL/WHT WIRE RED WIRE RED/WHT WIRE RED/YEL WIRE TAIL FUSE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE
