Geo Prizm II (1992-1997) from power door lock control module conn breakout) Wiring diagram

ACCESSORY FUSE ACCESSORY POWER RELAY (1996 ONLY) AUDIO ALARM MODULE BLK WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE DOOR KEY SWITCH DOOR LOCK CONTROL MODULE CONNECTOR BREAKOUT) DOOR LOCK RELAY DOOR LOCK TIMER DOOR UNLOCK RELAY DOOR UNLOCK TIMER DR LK RLY CTRL DR LK SIG FROM POWER DOOR LOCK CONTROL MODULE CONN BREAKOUT) FROM POWER DOOR LOCK CONTROL MODULE CONNECTOR BREAKOUT) GAUGE FUSE GRN WIRE GROUND IGNITION PWR DOOR OPEN SIG THEFT DET SIG HOT AT ALL TIMES HOT IN ON OR START J/B 1 (BEHIND LEFT KICK PANEL) J/B 3 (BEHIND CENTER OF I/P) J/C 1 (CENTER OF I/P, ON RIGHT I/P SUPPORT BRACE) LEFT FRONT DOOR JAMB SWITCH LEFT FRONT DOOR LOCK SWITCH LEFT FRONT POWER DOOR LOCK ACTUATOR LEFT FRONT POWER WINDOW, DOOR LOCK SWITCH LEFT FRONT SPEAKER CONN BREAKOUT) LEFT REAR POWER DOOR LOCK ACTUATOR LOCK NCA WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT POWER DOOR LOCK ACTUATOR RIGHT POWER DOOR LOCK SWITCH CONNECTOR (NOT USED) RIGHT REAR POWER DOOR LOCK ACTUATOR THEFT GND THEFT SIG TO 14-PIN CONNECTOR BEHIND LEFT KICK PANEL) UNLOCK W/ POWER WINDOWS W/O POWER WINDOWS WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE
