Geo Prizm II (1992-1997) from left i/p support brace gnd wire break out-1996) Wiring diagram
This page shows the only wiring diagram for the component.from left i/p support brace gnd wire break out-1996), which is found in the car Geo Prizm II (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram from left i/p support brace gnd wire break out-1996) (1 of 1)
1.6L
BLK WIRE
BLK/WHT WIRE
BREAK- OUT)
CLUTCH PEDAL POSITION SWITCH
CLUTCH PEDAL POSITION SWITCH CRUISE CONTROL DIODE
CRUISE CONTROL (DIODE)
CRUISE CONTROL MODULE
DAYTIME RUNNING LAMPS FUSE, RELAY BOX (RIGHT OF RADIATOR)
DAYTIME RUNNING LAMPS RELAY 3/4 (LEFT OF BRAKE PEDAL BRACKET)
DRL FUSE
DRL RELAY 2
ENGINE CONTROL MODULE
FROM 20-PIN CONN BREAK OUT BELOW RADIO)
FROM ECM
FROM FUSE, RELAY BOX (SCHEMATIC 1 OF 5)
FROM FUSE, RELAY BOX (SCHEMATIC 1 OF 6)
FROM IGNITION SWITCH (START) (SCHEMATIC 2 OF 6)
FROM INSTR CLUSTER CONN
FROM J/B 3
FROM LEFT I/P SUPPORT BRACE GND WIRE BREAK OUT-1996)
FROM PCM
FUSE, RELAY BOX (LEFT OF BRAKE PEDAL BRACKET)
HEADLAMP RELAY
INSTRUMENT CLUSTER
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LH HEAD FUSE
LH- LWR HEAD FUSE
LH-UPR HEAD FUSE
OUT-1995) (I/P HARN 1,
OUT-1996)
PARK/ NEUTRAL POSITION SWITCH
POWERTRAIN CONTROL MODULE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RH HEAD FUSE
RH- LWR HEAD FUSE
RH-UPR HEAD FUSE
RIGHT HIGH BEAM HEADLAMP
RIGHT HIGH-BEAM HEADLAMP CONN BREAKOUT)
RIGHT LOW BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP RIGHT HIGH BEAM HEADLAMP
Go to component -> Power distribution circuit (6 of 6) -> FROM LEFT I/P SUPPORT BRACE GND WIRE BREAK OUT-1996)
