Geo Prizm II (1992-1997) data link connector shield Wiring diagrams
This page contains all the electrical diagrams for the component. data link connector shield, in which he is found in the car Geo Prizm II (1992-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram data link connector shield (1 of 2)
1996 ONLY
BLK WIRE
BRAKE FLUID LEVEL SWITCH
BREAKOUT)
BRN WIRE
CALIFORNIA ONLY
DATA LINK CONNECTOR
DATA LINK CONNECTOR - ON-BOARD DIAGNOSTICS II (DCL-OBDII)
DATA LINK CONNECTOR SHIELD
DAYTIME RUNNING LAMPS (DRL) RELAY 3/4
DISTRIBUTOR SHIELD
ENGINE CONTROL MODULE
FROM JUNCTION BLOCK 3 (DIAGRAM 1 OF 4)
HIGH BEAM
INDICATOR
INSTRUMENT CLUSTER
JUNCTION BLOCK 1
KNOCK SENSOR SHIELD
LEFT HEADLAMP
LOW BEAM LAMP
M/T ONLY
NCA WIRE
NOT USED
OXYGEN SENSOR
OXYGEN SENSOR SHIELD
POWERTRAIN CONTROL MODULE
RED/YEL WIRE
RIGHT FRONT TURN LAMP
RIGHT HEADLAMP
RIGHT PARKING LAMP
RIGHT SIDE MARKER LAMP
SUB HEATED OXYGEN SENSOR
SUB OXYGEN SENSOR
SUB- HEATED OXYGEN SENSOR SHIELD
VIN 6
VIN 8
W/ ABS
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 4) -> DATA LINK CONNECTOR SHIELD
Wiring diagram data link connector shield (2 of 2)
1996 ONLY
A/C AMPLIFIER
A/T ONLY
BLK WIRE
BLOWER MOTOR RESISTOR
BLOWER SPEED SELECTOR SWITCH
BLU WIRE
BREAKOUT)
BRN WIRE
CLUTCH PEDAL POSITION INTERRUPT SWITCH
COMBINATION SWITCH
CRANKSHAFT POSITION SENSOR SHIELD
CRUISE CONTROL MODULE
CRUISE CONTROL SWITCH
DATA LINK CONNECTOR
DATA LINK CONNECTOR ON-BOARD DIAGNOSTICS II
DATA LINK CONNECTOR ON-BOARD DIAGNOSTICS II SHIELD
DATA LINK CONNECTOR SHIELD
DISTRIBUTOR SHIELD
ENGINE CONTROL MODULE (VIN 6)/
GRN WIRE
HEATED OXYGEN SENSOR 2
HEATED OXYGEN SENSOR 2 SHIELD
HEATER RELAY
IGNITION KEY WARNING SWITCH
INSTRUMENT CLUSTER
J/B 2
KNOCK SENSOR SHIELD
M/T ONLY
NCA WIRE
OXYGEN SENSOR 1
OXYGEN SENSOR 1 SHIELD
POWERTRAIN CONTROL MODULE (VIN 8)
REAR DEFOGGER
RELAY BLOCK CASSETTE IGNITION KEY LOCK SOLENOID (AUTOMATIC TRANSAXLE)
STARTER RELAY
SUPPLEMENTAL RESTRAINT SYSTEM COIL ASSEMBLY
TO J/B 3 (DIAGRAM 4 OF 4) (DIAGRAM 4 OF 4)
W/ ABS
W/ CRUISE CONTROL
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 4) -> DATA LINK CONNECTOR SHIELD
