Back-up lamps circuit for Geo Metro I (1989-1997)
Back-up lamps circuit
A/T
BACK FUSE
BACKUP
BACKUP LAMP
BACKUP LAMP SWITCH (TOP OF TRANSAXLE)
BLK WIRE
HOT IN ON AND START
JUNCTION BLOCK
LEFT REAR COMBINATION LAMP
M/T
REAR COMBINATION LAMP CONNECTOR BREAKOUT (4 DOOR) (NEAR DECK LID STRIKER)
RED WIRE
RIGHT REAR COMBINATION LAMP
TRANSAXLE RANGE SWITCH
TRANSMISSIONS SYSTEM
YEL WIRE
