Genesis GV80 I (2020-2023) w/ active noise w/ premium amplifier Wiring diagram
This page shows the only wiring diagram for the component.w/ active noise w/ premium amplifier, which is found in the car Genesis GV80 I (2020-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ active noise w/ premium amplifier (1 of 1)
AMP
AWD ECU
B-CAN
BLU WIRE
BRN WIRE
CCP-CAN HIGH
CCP-CAN LOW
DRIVER LUMBAR SUPPORT UNIT
DRIVER POWER SEAT MODULE
DRIVER POWER SEAT SWITCH
GRN WIRE
M-CAN
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PASSENGER POWER SEAT MODULE
RED WIRE
S-CAN
TCM
TRAILER CONNECTOR
W/ ACTIVE NOISE W/ PREMIUM AMPLIFIER
W/ STANDARD AMPLIFIER
WHT WIRE
Go to component -> Computer data lines circuit (4 of 9) -> W/ ACTIVE NOISE W/ PREMIUM AMPLIFIER
