Genesis GV80 I (2020-2023) temp sens sig pressure sens supply Wiring diagram
This page shows the only wiring diagram for the component.temp sens sig pressure sens supply, which is found in the car Genesis GV80 I (2020-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram temp sens sig pressure sens supply (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
E-LSD FUSE
ELSD CONTROL MODULE
ELSD MOTOR ASSEMBLY
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-D
MODULE 8 FUSE
MOTOR
MOTOR A
MOTOR B
NCA WIRE
ON/START IN MOTOR SHIELD
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PNK MEMORY PWR WIRE
PNK WIRE
PRESS SENS GND
PRESS SENS SIG
PRESSURE SENSOR
REAR JUNCTION BLOCK
RELAY ENERGIZED
RJ-A
TEMP SENS GND
TEMP SENS SIG PRESSURE SENS SUPPLY
TEMPERATURE SENSOR
WHT WIRE
WHT/BLK WIRE
YEL/BLK WIRE
Go to component -> Electronic limited slip differential system circuit -> TEMP SENS SIG PRESSURE SENS SUPPLY
