Genesis GV80 I (2020-2023) smart phone wireless charger indicator Wiring diagram
This page shows the only wiring diagram for the component.smart phone wireless charger indicator, which is found in the car Genesis GV80 I (2020-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram smart phone wireless charger indicator (1 of 1)
ARMREST LAMP
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
CENTER ROOM LAMP
FRONT CONSOLE SWITCH
FRONT CONSOLE USB CONNECTOR ASSEMBLY
FRONT TRAY LAMP
GRN WIRE
GRY WIRE
GRY/BLK WIRE
ILL
LED CONTROL LOGIC
LEFT REAR PERSONAL LAMP
NCA WIRE
NOT USED
OVERHEAD CONSOLE LAMP
PNK WIRE
REAR ROOM LAMP
RIGHT REAR PERSONAL LAMP
SMART PHONE WIRELESS CHARGER INDICATOR
W/ SUNROOF
W/O SUNROOF
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 3) -> SMART PHONE WIRELESS CHARGER INDICATOR
