Genesis GV80 I (2020-2023) gry Wiring diagrams

This page contains all the electrical diagrams for the component. gry, in which he is found in the car Genesis GV80 I (2020-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram gry (101 of 152)

Wiring diagram gry for Genesis GV80 I (2020-2023) (101 of 152)

Get access

'B' OUTPUT 12.3 INCH 8 INCH COLOR AWD LOCK IND BLK WIRE BLU WIRE BLU/BLK WIRE CLUSTER FUSE COMPUTER DATA LINES SYSTEM DIMMABLE E/R JUNCTION BLOCK E/R SUB JUNCTION BLOCK GCU GROUND GRY WIRE HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-H INSTRUMENT CLUSTER LDC FUSE LOW DC-DC CONVERTER (RIGHT END OF DASH) M-CAN MEMORY POWER MICOM MODULE 2 FUSE MULTI FUSE MULTI POWER ON/START INPUT ORG/ WIRE P-CAN HIGH P-CAN LOW PCB BLOCK RED WIRE RELAY ENERGIZED SIG 1 GND SUPPLY TFT LCD TRANSCEIVER/ W/ 8 INCH TFT LCD DISPLAY

Go to component -> 4wd circuit -> GRY WIRE

Wiring diagram gry (102 of 152)

Wiring diagram gry for Genesis GV80 I (2020-2023) (102 of 152)

Get access

ACC/ON INPUT ACTUATOR BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CCP-CAN HIGH CCP-CAN LOW COMPUTER DATA LINES SYSTEM D-SOL 27 D-SOL 4, OD D-SOL 6 D-SOL UD DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR OPEN SIG E-SHIFTER 1 FUSE E-SHIFTER 2 FUSE ELECTRONIC ATM SHIFT LEVER DIAL GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ HOT W/ ACC RELAY ENERGIZED HOT W/ SHORT TERM LOAD LATCH RELAY ENERGIZED ICU JUNCTION BLOCK ICU-G ICU-H INHIBIT SW GND INHIBIT SW SUPPLY INPUT SPEED SIG MEMORY PWR B+ MEMORY PWR PRA MODULE 3 FUSE MODULE 6 FUSE MOTOR GND NOT P POSITION OIL TEMP SENSOR ON/OFF REV ON/START INPUT ORG/ WIRE ORG/BLK WIRE OUTPUT SPEED SIG P POSITION P-CAN HIGH P-CAN LOW P/N RELAY CTRL PCB BLOCK PNK WIRE PWR GND RED WIRE SENSOR 1 GND SENSOR 1 INPUT SENSOR 1 SUPPLY SENSOR 2 GND SENSOR 2 INPUT SENSOR 2 SUPPLY STARTING/CHARGING SYSTEM STOP SWITCH TCM TCU 2 FUSE VFS DC VFS LP WHT WIRE YEL WIRE

Go to component -> A/t circuit (1 of 3) -> GRY WIRE

Wiring diagram gry (103 of 152)

Wiring diagram gry for Genesis GV80 I (2020-2023) (103 of 152)

Get access

ATM SOLENOID VALVE (LEFT SIDE OF TRANSMISSION) BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CLOCKSPRING D-SOL 27 D-SOL 4, OD D-SOL 6 D-SOL UD E/R JUNCTION BLOCK GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES INPUT SPEED SENSOR OIL TEMPERATURE SENSOR ON/OFF DRIVE ON/OFF PARKING ON/OFF REVERSE ORG/ WIRE ORG/BLK WIRE OUTPUT SPEED SENSOR PNK WIRE RED WIRE TCU 1 FUSE VFS DC VFS LP WHT WIRE YEL WIRE YEL/BLK WIRE

Go to component -> A/t circuit (2 of 3) -> GRY WIRE

Wiring diagram gry (104 of 152)

Wiring diagram gry for Genesis GV80 I (2020-2023) (104 of 152)

Get access

B+1 FUSE B-CAN HIGH B-CAN LOW BAT-A BATTERY JUNCTION BLOCK BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR SWITCH ELECTRONIC ATM SHIFT LEVER DIAL GRN WIRE GRY WIRE HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-A ICU-B ICU-D ICU-E ICU-H IEB UNIT IPS CONTROL MODULE LEFT REAR DOOR SWITCH ORG/ WIRE PASS DOOR SWITCH PASSENGER DOOR MOOD LAMP UNIT PNK/BLK WIRE REAR OCCUPANT ALERT (ROA) SENSOR RED WIRE RIGHT REAR DOOR RIGHT REAR DOOR MOOD LAMP UNIT RIGHT REAR DOOR SWITCH WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Courtesy lamps circuit (2 of 5) -> GRY WIRE

Wiring diagram gry (105 of 152)

Wiring diagram gry for Genesis GV80 I (2020-2023) (105 of 152)

Get access

B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CENTER GARNISH MOOD LAMP CENTER ROOM LAMP COMPUTER DATA LINES SYSTEM DOOR SIG DRIVER DOOR MOOD LAMP UNIT DRIVER'S DOOR GRN WIRE GRY WIRE ILL INSTRUMENT ILLUMINATION CIRCUIT LED CONTROL LOGIC LEFT GARNISH MOOD LAMP LEFT REAR DOOR MOOD LAMP UNIT LEFT REAR PERSONAL LAMP MOOD LAMP UNIT (CENTER OF DASH) ORG/ WIRE PNK/BLK WIRE REAR ROOM LAMP RED WIRE RIGHT GARNISH MOOD LAMP RIGHT REAR PERSONAL LAMP ROOM LAMP SIG W/ SUNROOF W/O SUNROOF WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Courtesy lamps circuit (3 of 5) -> GRY WIRE

Wiring diagram gry (106 of 152)

Wiring diagram gry for Genesis GV80 I (2020-2023) (106 of 152)

Get access

8 INCH COLOR TFT BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CONSOLE MOOD LAMP DOOR DOOR SIG GND SIG 1 GRN WIRE GROUND GRY WIRE ILL INSTRUMENT CLUSTER INSTRUMENT ILLUMINATION CIRCUIT LED CONTROL LOGIC LEFT SUN VISOR LAMP SWITCH LEFT SUN- VISOR LAMP LEFT VANITY LAMP M-CAN TRANSCEIVER MICOM ORG/ WIRE OVERHEAD CONSOLE LAMP PNK/BLK WIRE RED WIRE RIGHT END OF DASH) RIGHT SUN VISOR LAMP SWITCH RIGHT SUN- VISOR LAMP RIGHT VANITY LAMP ROOM LAMP SIG TFT LCD (DOOR OPEN/ TAIL GATE OPEN) WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Courtesy lamps circuit (4 of 5) -> GRY WIRE

Wiring diagram gry (107 of 152)

Wiring diagram gry for Genesis GV80 I (2020-2023) (107 of 152)

Get access

ACCEL PEDAL POSITION SENSOR APS 1 GND APS 1 SIG APS 1 SUPPLY APS 2 GND APS 2 SIG APS 2 SUPPLY AUDIO SW B-CAN BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BRK SIG BRK LAMP SIG BRN WIRE BRN/ORG WIRE CH 1+ CH 2+ CLOCKSPRING COMPUTER DATA LINES SYSTEM CRUISE SLD DOWN E-CAN HIGH E-CAN LOW ECU 4 FUSE ENCODER ENGINE CTRL RLY ON INPUT ETC MOTOR, +/- GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GROUND GRY WIRE HAPTIC MOTOR HOT W/ ENGINE CONTROL RELAY ENERGIZED ILL ILL (+) IN LEFT PADDLE SHIFT (DOWN) SWITCH LEFT STEERING WHEEL REMOTE CONTROL SWITCH LOCAL CAN HIGH LOCAL CAN LOW LT GRN WIRE MEM PWR MODULE 2 FUSE NCA WIRE ON/START INPUT ORG/ WIRE OUT OUT SW 1 OUT SW 2 P-CAN HIGH P-CAN LOW PADDLE PCB BLOCK PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RELAY ENERGIZED RES CANCEL RIGHT PADDLE SHIFT (UP) SWITCH RIGHT STEERING WHEEL REMOTE CONTROL SWITCH SHIFT SMART CRUISE CONTROL RADAR SSC STEERING WHEEL) TPS 1 SIG TPS 2 SIG TPS GND TPS SUPPLY TRIP VEHICLE SPEED SIG WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Cruise control circuit (1 of 3) -> GRY WIRE

Wiring diagram gry (108 of 152)

Wiring diagram gry for Genesis GV80 I (2020-2023) (108 of 152)

Get access

A/V, NAVIGATION HEAD UNIT A/V, NAVIGATION KEYBOARD B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BLU/BLK WIRE CLUSTER FUSE COMPUTER DATA LINES SYSTEM CRASH PAD SWITCH DOWN ELECTRONIC PARKING BRAKE SWITCH FRONT A/C CONTROLLER FRONT CONSOLE KEYBOARD GRN WIRE GROUND GRY WIRE GRY/BLK WIRE HEADLAMP AUTO SWITCH HEADLAMP LOW SWITCH HEADLAMP OFF SWITCH HEADLAMP TAIL SWITCH HOT W/ ACC RELAY ENERGIZED HOT W/ SHORT TERM LOAD LATCH RELAY ENERGIZED ICU JUNCTION BLOCK ICU-A ICU-E ICU-G ICU-H ILL IPS CONTROL MODULE LEFT LANE SWITCH LEFT TURN SWITCH LOGIC MODULE 3 FUSE MODULE 6 FUSE MODULE 7 FUSE MULTI- FUNCTION SWITCH ORG/ WIRE PNK WIRE REAR A/C CONTROLLER PANEL REAR AUTOMATIC A/C REAR MANUAL A/C REAR USB CHARGER RELAY ENERGIZED RHEOSTAT RIGHT LANE SWITCH RIGHT TURN SWITCH SBC YEL WIRE

Go to component -> Instrument illumination circuit (1 of 3) -> GRY WIRE

Wiring diagram gry (109 of 152)

Wiring diagram gry for Genesis GV80 I (2020-2023) (109 of 152)

Get access

ARMREST LAMP BLK WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE CENTER ROOM LAMP FRONT CONSOLE SWITCH FRONT CONSOLE USB CONNECTOR ASSEMBLY FRONT TRAY LAMP GRN WIRE GRY WIRE GRY/BLK WIRE ILL LED CONTROL LOGIC LEFT REAR PERSONAL LAMP NCA WIRE NOT USED OVERHEAD CONSOLE LAMP PNK WIRE REAR ROOM LAMP RIGHT REAR PERSONAL LAMP SMART PHONE WIRELESS CHARGER INDICATOR W/ SUNROOF W/O SUNROOF YEL WIRE

Go to component -> Instrument illumination circuit (2 of 3) -> GRY WIRE

Wiring diagram gry (110 of 152)

Wiring diagram gry for Genesis GV80 I (2020-2023) (110 of 152)

Get access

3 COLOR MOOD RING IND BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE COMPUTER DATA LINES SYSTEM CONSTANT CURRENT DETENT OUT DIAL ILLUMINATION DOWN DRIVER DOOR OUTSIDE HANDLE MOOD LAMP GRN WIRE GROUND GRY WIRE IG 1 ILL IMS SWITCH INSTRUMENT CLUSTER IR LED + IR LED DRV LEFT REAR DOOR MODULE LEFT REAR OUTSIDE HANDLE MOOD LAMP M-CAN HIGH M-CAN LOW M-CAN TRANSCEIVER MICOM PASSENGER DOOR MODULE PASSENGER DOOR OUTSIDE HANDLE MOOD LAMP POINTER ILLUMINATION REAR A/C CONTROL PANEL RED WIRE RIGHT REAR DOOR MODULE RIGHT REAR DOOR OUTSIDE HANDLE MOOD LAMP YEL WIRE YEL/BLK WIRE

Go to component -> Instrument illumination circuit (3 of 3) -> GRY WIRE
