Genesis GV80 I (2020-2023) foot lamp out Wiring diagram
This page shows the only wiring diagram for the component.foot lamp out, which is found in the car Genesis GV80 I (2020-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram foot lamp out (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CLUSTER FUSE
DRIVER DOOR FOOT LAMP
DRIVER FRONT DOOR FOOT LAMP OUT
DRIVER SEAT FOOT LAMP
FOOT LAMP OUT
GLOVE BOX LAMP)
GLOVE BOX LAMP/ SWITCH
GRN WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-A
ICU-D
ICU-E
ICU-G
ICU-H
LEFT
LEFT FOOT LAMP
LEFT LUGGAGE LAMP
LEFT REAR DOOR FOOT LAMP
LSD
LUGGAGE LAMP OUT
MODULE 4 FUSE
ORG/ WIRE
PASSENGER DOOR FOOT LAMP
PASSENGER FRONT DOOR FOOT LAMP OUT
PASSENGER SEAT FOOT LAMP
POWER DISTRIBUTION SYSTEM
REAR DOOR FOOT LAMP OUT
RED WIRE
RELAY ENERGIZED
RIGHT FOOT LAMP
RIGHT LUGGAGE LAMP
RIGHT REAR DOOR FOOT LAMP
RIGHT REAR DOOR FOOT LAMP OUT
ROOM LAMP OUT
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Courtesy lamps circuit (1 of 5) -> FOOT LAMP OUT
