Genesis GV80 I (2020-2023) ble unit Wiring diagrams
This page contains all the electrical diagrams for the component. ble unit, in which he is found in the car Genesis GV80 I (2020-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ble unit (1 of 2)
A/V, NAVIGATION HEAD UNIT
BLE UNIT
BLK WIRE
BRAKE FLUID LEVEL SENSOR
COOLING FAN MOTOR
EXTERNAL BUZZER
FRONT CONSOLE KEY- BOARD
FRONT CONSOLE USB CONNECTOR ASSEMBLY
FRONT FET (FIELD EFFECT TRANSISTOR)
FRONT MONITOR
IAU
IBU
IEB UNIT
LEFT FRONT CENTER PDW SENSOR
LEFT FRONT PDW SENSOR
LEFT FRONT RADAR
LEFT FRONT SIDE PDW SENSOR
LEFT HEADLAMP
LOW DC-DC CONVERTER
MDPS UNIT
NCA WIRE
RIGHT FRONT CENTER PDW SENSOR
RIGHT FRONT PDW SENSOR
RIGHT FRONT RADAR
RIGHT FRONT SIDE PDW SENSOR
START STOP BUTTON SWITCH
STOP LAMP SWITCH
W/ SMART PARKING ASSIST
W/ SURROUND VIEW MONITOR
WASHER LEVEL SENSOR
WASHER MOTOR
WIPER MOTOR
Go to component -> Ground distribution circuit (2 of 8) -> BLE UNIT
Wiring diagram ble unit (2 of 2)
A/V, NAVIGATION HEAD UNIT
AIR BAG 1 FUSE
BACKUP LP
BLE UNIT
BLU WIRE
BLU/BLK WIRE
BRAKE LP RH
DRIVER DOOR OUTSIDE HANDLE
DRIVER LUMBAR SUPPORT UNIT
DRIVER POWER SEAT MODULE
DRIVER POWER SEAT SWITCH
E-SHIFTER FUSE
ELECTROCHROMIC MIRROR
ELECTRONIC ATM SHIFT LEVER DIAL
EXT TAIL LP RL
FROM REAR JUNCTION BLOCK (DIAGRAM 8 OF 14)
GRN WIRE
GRN/BLK WIRE
IAU
IBU
IBU 1 FUSE
ICU-A
ICU-B
ICU-C
ICU-D
ICU-G
ICU-H
IPS 2 CTRL
IPS 5 CTRL
IPS CONTROL MODULE
LEFT BACKUP LAMP
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (IN)
MODULE 5 FUSE
NCA WIRE
ORG/ WIRE
P/DOOR RH
PASSENGER DOOR LATCH
PASSENGER DOOR OUTSIDE HANDLE
POWER TAILGATE UNIT
RED WIRE
RED/BLK WIRE
RIGHT BACKUP LAMP
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT REAR DOOR LATCH
SPARE (B+) FUSE
SRS CONTROL MODULE
W/ 2 CELL
WHT WIRE
Go to component -> Power distribution circuit (14 of 14) -> BLE UNIT
