Genesis GV70 I (2020-2024) t/sig lp rl wiring diagram
This page shows the only wiring diagram for the component.t/sig lp rl, which is found in the car Genesis GV70 I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
t/sig lp rl wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE LP LH
BRN WIRE
BRN/BLK WIRE
DRIVER DOOR FOOT LAMP
DRIVER POWER OUTSIDE MIRROR
ELECTRONIC BRAKE CONTROLLER
EXT TAIL
FROM BRAKE SWITCH FUSE (DIAGRAM 6 OF 15)
GLOVE BOX LAMP)
HIGH MOUNTED STOP LAMP
HMSL
ICU JUNCTION BLOCK
ICU-A
ICU-H
IPS
IPS 1 CTRL
IPS 3 CTRL
IPS 4 CTRL
IPS CONTROL MODULE
LEFT FOOT LAMP
LEFT LUGGAGE LAMP
LEFT REAR COMBINATION LAMP (IN)
LEFT REAR COMBINATION LAMP (OUT)
LEFT REAR PERSONAL LAMP
LEFT SUN- VISOR LAMP
LP LOAD
LP RR
NCA WIRE
OVERHEAD CONSOLE LAMP
PASSENGER DOOR FOOT LAMP
RED WIRE
RIGHT FOOT LAMP
RIGHT LICENSE LAMP
RIGHT LUGGAGE LAMP
RIGHT REAR COMBINATION LAMP (IN)
RIGHT REAR COMBINATION LAMP (OUT)
RIGHT REAR PERSONAL LAMP
RIGHT SUN- VISOR LAMP
ROOM LAMP
T/SIG LP RL
TAIL LP
TO ICU JUNCTION BLOCK (DIAGRAM 8 OF 15)
TRAILER CONNECTOR
W/ SUNROOF
W/O SUNROOF
Go to component -> Power distribution circuit (7 of 15) -> T/SIG LP RL
