Genesis GV70 I (2020-2024) pre safety seat belt 2 fuse Wiring diagrams
This page contains all the electrical diagrams for the component. pre safety seat belt 2 fuse, in which he is found in the car Genesis GV70 I (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pre safety seat belt 2 fuse (1 of 2)
AMP FUSE
B+2 FUSE
BLU WIRE
BRN WIRE
CHILD LOCK FUSE
CHILD LOCK RELAY
CHILD UNLOCK RELAY
E-LSD FUSE
ELSD CONTROL MODULE
FROM BATTERY JUNCTION BLOCK (DIAGRAM 1 OF 15)
GRN WIRE
ORG/ WIRE
P/WINDOW RH FUSE
PASSENGER POWER WINDOW MODULE
PNK WIRE
POWER TAILGATE FUSE
POWER TAILGATE UNIT
PRE SAFETY SEAT BELT 1 FUSE
PRE SAFETY SEAT BELT 2 FUSE
PRE-ACTIVE SEAT BELT UNIT
REAR AIR VENTILATION SEAT CONTROL MODULE
REAR SEAT WARMER CONTROL MODULE
REAR WIPER MOTOR
REAR WIPER RELAY
RED WIRE
RIGHT REAR POWER WINDOW MODULE
RJ-A
RJ-D
S/HEATER PASS 2 FUSE
S/HEATER RR 1 FUSE
S/HEATER RR 2 FUSE
TO ICU JUNCTION BLOCK (DIAGRAM 15 OF 15)
TO LOW DC-DC CONVERTER (AMP) (DIAGRAM 10 OF 15)
W/ WARMER
WHT WIRE
WIPER RR FUSE
Go to component -> Power distribution circuit (9 of 15) -> PRE SAFETY SEAT BELT 2 FUSE
Wiring diagram pre safety seat belt 2 fuse (2 of 2)
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
COMPUTER DATA LINES SYSTEM
DRIVER MTR (-)
GRN WIRE
GROUND
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
IBU
LED CONTROL LOGIC
MEM PWR
ON/START INPUT
OVERHEAD CONSOLE
PAB OFF IND
PASS MTR (+)
PASSENGER AIR BAG 1
PASSENGER AIR BAG 2
PASSENGER OCCUPANT DETECTION SENSOR
PNK WIRE
PNK/BLK WIRE
PRE SAFETY SEAT BELT 1 FUSE
PRE SAFETY SEAT BELT 2 FUSE
PRE-ACTIVE SEAT BELT UNIT
REAR JUNCTION BLOCK
REAR OCCUPANT ALERT (ROA) SENSOR
RED WIRE
RJ-A
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 4) -> PRE SAFETY SEAT BELT 2 FUSE
