Genesis GV70 I (2020-2024) hot w/ long term load relay energized Wiring diagram
This page shows the only wiring diagram for the component.hot w/ long term load relay energized, which is found in the car Genesis GV70 I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ long term load relay energized (1 of 1)
A/BAG IND FUSE
AIR BAG 1 FUSE
AIR BAG 2 FUSE
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
C-CAN HIGH
C-CAN LOW
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
CRASH OUTPUT
CRASH UNLOCK
DRIVER AIR BAG
DRIVER FRONT IMPACT SENS (HIGH)
DRIVER FRONT IMPACT SENS (LOW)
DRIVER FRONT IMPACT SENSOR
DRIVER KNEE AIR BAG
DRIVER KNEE AIR BAG (HIGH)
DRIVER KNEE AIR BAG (LOW) PAB OFF IND
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT W/ IG 1 RELAY ENERGIZED
HOT W/ LONG TERM LOAD RELAY ENERGIZED
ICU JUNCTION BLOCK
ICU-A
ICU-E
ICU-G
ICU-H
IPS CONTROL MODULE
MEMORY POWER
MODULE 3 FUSE
NCA WIRE
ON/START INPUT
PASS FRONT IMPACT SENS HIGH
PASS FRONT IMPACT SENS LOW
PASSENGER FRONT IMPACT SENSOR
PNK/BLK WIRE
PRE SAFETY SEAT BELT 3 FUSE
RED WIRE
SRS CONTROL MODULE (CENTER OF FLOOR CONSOLE)
STEERING WHEEL)
WHT WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (1 of 4) -> HOT W/ LONG TERM LOAD RELAY ENERGIZED
