Genesis GV70 I (2020-2024) a/v, navigation keyboard Wiring diagram
This page shows the only wiring diagram for the component.a/v, navigation keyboard, which is found in the car Genesis GV70 I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/v, navigation keyboard (11 of 11)
A/V, NAVIGATION HEAD UNIT
A/V, NAVIGATION KEYBOARD
BLU WIRE
BLU/ORG WIRE
CRASH PAD SWITCH
DRIVER DOOR OUTSIDE HANDLE MOOD LAMP
ELECTRONIC PARKING BRAKE SWITCH
FRONT CONSOLE KEYBOARD
FRONT CONSOLE SWITCH
FRONT CONSOLE USB CONNECTOR ASSEMBLY
ICU JUNCTION BLOCK
ICU-A
ICU-H
IMS SWITCH
LEFT REAR DOOR MODULE
LEFT REAR DOOR OUTSIDE HANDLE MOOD LAMP
LEFT REAR PERSONAL LAMP
NCA WIRE
OVERHEAD CONSOLE LAMP
PASSENGER DOOR MODULE
PASSENGER DOOR OUTSIDE HANDLE MOOD LAMP
REAR A/C CONTROLLER
REAR SEAT HEATER SWITCH
RIGHT REAR DOOR MODULE
RIGHT REAR DOOR OUTSIDE HANDLE MOOD LAMP
RIGHT REAR PERSONAL LAMP
ROOM LAMP (CENTER)
TO REAR USB CHARGER (DIAGRAM 10 OF 15)
TO SMART PHONE WIRELESS CHARGER INDICATOR (DIAGRAM 11 OF 15)
W/ SUNROOF
W/O SUNROOF
W/O WIRELESS CHARGING
YEL/BLK WIRE
Go to component -> Power distribution circuit (8 of 15) -> A/V, NAVIGATION KEYBOARD
