Genesis GV70 I (2020-2024) 8 inch color display tft lcd wiring diagram
This page shows the only wiring diagram for the component.8 inch color display tft lcd, which is found in the car Genesis GV70 I (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
8 inch color display tft lcd wiring diagram (1 of 1)
8 INCH COLOR DISPLAY TFT LCD
A/C PRESSURE TRANSDUCER
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CHECK ENGINE IND
COMPUTER DATA LINES SYSTEM
FUEL SENDER INPUT (-)
GCU
GRN WIRE
GRN/BLK WIRE
GRY WIRE
IC IGNITER
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
INJECTOR 2 (HPDI)
INJECTOR 3 (HPDI)
INSTRUMENT CLUSTER
M-CAN TRANSCEIVER
MASTER IND
MICOM
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
SIG 1 GND
W/ 8 INCH TFT LCD DISPLAY
YEL WIRE
Go to component -> Wiring diagram engine performance 2.5l turbo, engine controls circuit (8 of 9) -> 8 INCH COLOR DISPLAY TFT LCD
