Genesis G80 II (2020-2024) w/ standard amplifier w/ premium amplifier w/ active noise Wiring diagram
This page shows the only wiring diagram for the component.w/ standard amplifier w/ premium amplifier w/ active noise, which is found in the car Genesis G80 II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ standard amplifier w/ premium amplifier w/ active noise (1 of 1)
A/C CONTROL MODULE
ADAS UNIT (DRIVING)
ADAS-CAN HIGH
ADAS-CAN LOW
AMP
BLK WIRE
BLU WIRE
BLU/BLK WIRE
CCP-CAN HIGH
CCP-CAN LOW
CLIMATE CAN
CLIMATE CAN HIGH
CLIMATE CAN LOW
E-CAN HIGH
E-CAN LOW
ELECTRONIC OIL PUMP
FRONT A/C CONTROLLER
FUEL PUMP CONTROL MODULE
GRN WIRE
GRN/ORG WIRE
LEFT REAR RADAR
LOCAL CAN HIGH
LOCAL CAN LOW
M-CAN HIGH
M-CAN LOW
ORG/ WIRE
RED WIRE
RED/BLK WIRE
W/ FRONT CORNER RADAR
W/ STANDARD AMPLIFIER W/ PREMIUM AMPLIFIER W/ ACTIVE NOISE
W/O FRONT CORNER RADAR
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (8 of 9) -> W/ STANDARD AMPLIFIER W/ PREMIUM AMPLIFIER W/ ACTIVE NOISE
