Genesis G80 II (2020-2024) tft lcd wiring diagram
This page shows the only wiring diagram for the component.tft lcd, which is found in the car Genesis G80 II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
tft lcd wiring diagram (1 of 1)
'B' OUTPUT
8 INCH COLOR
AWD ECU (BOTTOM REAR OF TRANSMISSION)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
DIMMABLE
E/R JUNCTION BLOCK
E/R SUB JUNCTION BLOCK
E/R-A
GCU
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED
ICU JUNCTION BLOCK
ICU-G
ICU-H
INSTRUMENT CLUSTER
LDC FUSE
LOW DC-DC CONVERTER
M-CAN
MEMORY POWER
MICOM
MODULE 2 FUSE
MULTI FUSE
MULTI MEDIA FUSE
ON/START INPUT
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PCB BLOCK
POWER DISTRIBUTION SYSTEM
RED WIRE
RELAY ENERGIZED
SIG 1 GND
TFT LCD
TRANSCEIVER/
W/ 8 INCH TFT LCD DISPLAY
Go to component -> 4wd circuit -> TFT LCD
