Genesis G80 II (2020-2024) sxm out/vin Wiring diagrams
This page contains all the electrical diagrams for the component. sxm out/vin, in which he is found in the car Genesis G80 II (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sxm out/vin (1 of 6)
Go to component -> Navigation circuit, w/ active noise (5 of 9) -> SXM OUT/VIN
Wiring diagram sxm out/vin (2 of 6)
Go to component -> Navigation circuit, w/ premium amplifier (5 of 8) -> SXM OUT/VIN
Wiring diagram sxm out/vin (3 of 6)
Go to component -> Navigation circuit, w/ standard amplifier (5 of 7) -> SXM OUT/VIN
Wiring diagram sxm out/vin (4 of 6)
Go to component -> Radio circuit, w/ active noise (5 of 9) -> SXM OUT/VIN
Wiring diagram sxm out/vin (5 of 6)
Go to component -> Radio circuit, w/ premium amplifier (5 of 8) -> SXM OUT/VIN
Wiring diagram sxm out/vin (6 of 6)
Go to component -> Radio circuit, w/ standard amplifier (5 of 7) -> SXM OUT/VIN
