Genesis G80 II (2020-2024) on/off reverse Wiring diagram
This page shows the only wiring diagram for the component.on/off reverse, which is found in the car Genesis G80 II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram on/off reverse (1 of 1)
ATM SOLENOID VALVE (LEFT SIDE OF TRANSMISSION)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
CLOCKSPRING
D-SOL 27
D-SOL 4, OD
D-SOL 6
D-SOL UD
E/R JUNCTION BLOCK
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
INPUT SPEED SENSOR
OIL TEMPERATURE SENSOR
ON/OFF DRIVE
ON/OFF PARKING
ON/OFF REVERSE
ORG/ WIRE
ORG/BLK WIRE
OUTPUT SPEED SENSOR
PNK WIRE
RED WIRE
TCU 1 FUSE
VFS DC
VFS LP
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> A/t circuit (2 of 3) -> ON/OFF REVERSE
