Genesis G80 II (2020-2024) memory pwr on input Wiring diagram
This page shows the only wiring diagram for the component.memory pwr on input, which is found in the car Genesis G80 II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory pwr on input (1 of 1)
'B' OUTPUT
APPLY SWITCH 1
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DRL
EBP SW SIG SW 1
EBP SW SIG SW 2
EBP SW SIG SW 3
EBP SW SIG SW 4
ELECTRONIC PARKING BRAKE SWITCH
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
IBU (RIGHT SIDE OF DASH)
IEB UNIT (LEFT REAR OF ENGINE COMPT)
ILL
LOW DC-DC CONVERTER (BEHIND LEFT SIDE OF DASH)
MEMORY POWER
MEMORY PWR
MEMORY PWR ON INPUT
NCA WIRE
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
RAIN SENSOR
RED WIRE
RELEASE SWITCH 2
RIGHT HEADLAMP
SIDE REPEATER
SW 1
SW 2
SW 3
SW 4
WHT WIRE
WIPER MOTOR
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlights circuit (2 of 2) -> MEMORY PWR ON INPUT
