Genesis G80 II (2020-2024) local-can low adas-can low Wiring diagram
This page shows the only wiring diagram for the component.local-can low adas-can low, which is found in the car Genesis G80 II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram local-can low adas-can low (1 of 1)
ADAS-CAN HIGH
ADAS-CAN HIGH LOCAL-CAN HIGH
ADAS-CAN LOW
BLK WIRE
BLU WIRE
BLU/BLK WIRE
CLIMATE CAN HIGH
CLIMATE CAN LOW
E-CAN HIGH
E-CAN LOW
GRN WIRE
GRN/ORG WIRE
LEFT FRONT RADAR
LEFT REAR SEAT HEATER UNIT
LKAS UNIT
LOCAL CAN HIGH
LOCAL CAN LOW
LOCAL-CAN LOW ADAS-CAN LOW
ORG/ WIRE
REAR A/C CONTROLLER
RED WIRE
RED/BLK WIRE
RIGHT FRONT RADAR
RIGHT REAR RADAR
S-CAN
SMART CRUISE CONTROL RADAR
W/ FRONT CORNER RADAR
W/O FRONT CORNER RADAR
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Computer data lines circuit (7 of 9) -> LOCAL-CAN LOW ADAS-CAN LOW
