Genesis G80 II (2020-2024) gry Wiring diagrams
This page contains all the electrical diagrams for the component. gry, in which he is found in the car Genesis G80 II (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram gry (141 of 143)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
CCP-CAN HIGH
CCP-CAN LOW
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE SENSOR (OUT)
ELECTRIC WASTEGATE ACTUATOR 1
ELECTRIC WASTEGATE ACTUATOR 2
EWGA MOTOR 1 (-)
GRN WIRE
GRY WIRE
IC IGNITER
IGN COIL CTRL 2
IGN COIL CTRL 4
IGN COIL CTRL 6
IGNITION COIL 2
IGNITION COIL 4
IGNITION COIL 6
INJ 1 CTRL HIGH
INJ 1 CTRL LOW
INJ 2 CTRL HIGH
INJ 2 CTRL LOW
INJ 4 CTRL HIGH
INJ 4 CTRL LOW
INJECTOR 1 (GDI)
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
POS SENS FEEDBACK SIG
RED WIRE
SENS GND
SENS SHIELD
SENS SIG
WHT WIRE
WTS OUT GND
WTS OUT SIG
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l turbo, engine controls circuit (2 of 8) -> GRY WIRE
Wiring diagram gry (142 of 143)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CLUSTER FUSE
ECM (LEFT FRONT SIDE OF ENGINE COMPT)
ECU 2 FUSE
ECU 3 FUSE
ECU 4 FUSE
ENGINE CONTROL RELAY
EWGA MOTOR 1 (-)
EWGA MOTOR 2 (-)
EWP FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-H
IGN COIL FUSE
INJ CTRL (MPI) 2
INJ CTRL (MPI) 4
INJ CTRL (MPI) 6
MODULE 8 FUSE
OCV CTRL (EXHAUST) 2
OCV CTRL (EXHAUST) 4
OCV CTRL (INTAKE) 1
OCV CTRL (INTAKE) 3
OIL CONTROL VALVE 1
OIL CONTROL VALVE 2
OIL CONTROL VALVE 3
OIL PMP SOL VALVE CTRL
OIL PUMP SOLENOID VALVE
ORG/ WIRE
ORG/BLK WIRE
PCB BLOCK
PCSV CTRL
PNK WIRE
PURGE CONTROL SOLENOID VALVE
RCV CONTROL SOLENOID VALVE 2
RCV SOL VALVE 2
RED WIRE
RED/BLK WIRE
RELAY ENERGIZED
SENSOR 1 FUSE
SENSOR 2 FUSE
SENSOR 3 FUSE
WHT WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l turbo, engine controls circuit (4 of 8) -> GRY WIRE
Wiring diagram gry (143 of 143)
ACCEL PEDAL POSITION SENSOR
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CCP-CAN HIGH
CCP-CAN LOW
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
EMPTY
FUEL LEVEL FLOAT
FUEL PRESSURE SENSOR
FUEL PUMP
FUEL PUMP CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT)
FUEL PUMP RLY
FUEL PUMP U
FUEL PUMP V
FUEL PUMP W
FUEL SENDER (MAIN)
FUEL SENDER (SUB)
FUEL TANK ASSEMBLY
FUEL TANK PRESSURE SENSOR
FULL
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HTR
INJECTOR 1 (MPI)
INJECTOR 3 (MPI)
INJECTOR 5 (MPI)
ISG OFF SWITCH
LOGIC
NCA WIRE
ON INPUT
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
PRESS SENS GND
PRESS SENS SIG
PRESS SENS SPLY
PUMP
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
SHIELD GND
SIG
SPLY
WHT WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l turbo, engine controls circuit (7 of 8) -> GRY WIRE
