Genesis G80 II (2020-2024) blk Wiring diagrams

This page contains all the electrical diagrams for the component. blk, in which he is found in the car Genesis G80 II (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

blk wiring diagram (141 of 195)

'B' OUTPUT ADAS UNIT (DRIVING) ADAS-CAN HIGH ADAS-CAN LOW ADAS-CAN LOW PNK ON/START INPUT WIRE BCW IND BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DRIVER POWER OUTSIDE MIRROR DRIVER'S DOOR E-CAN HIGH E-CAN LOW E-CAN LOW PNK ON/START INPUT WIRE E/R SUB JUNCTION BLOCK E/R-A GRN WIRE GROUND HOT W/ HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED ICU JUNCTION BLOCK ICU-D ICU-G ICU-H ISG B+ INPUT LDC FUSE LEFT FRONT RADAR LEFT REAR RADAR LOCAL CAN HIGH LOCAL CAN LOW LOW DC-DC CONVERTER MEMORY POWER MODULE 2 FUSE MODULE 8 FUSE MULTI MEDIA FUSE ON/START INPUT ORG/ WIRE PASSENGER POWER OUTSIDE MIRROR PCB BLOCK PNK WIRE PNK/BLK WIRE RED WIRE RELAY ENERGIZED RIGHT FRONT RADAR RIGHT REAR RADAR W/ FRONT CORNER RADAR WHT WIRE WHT/ORG WIRE YEL WIRE

Go to component -> Blind spot information system circuit -> BLK WIRE

blk wiring diagram (142 of 195)

BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CENTER SPEAKER DRIVER DOOR MIDRANGE SPEAKER DRIVER DOOR TWEETER SPEAKER DRIVER POWER OUTSIDE MIRROR ETHERNET GRN WIRE GRN/BLK WIRE GRY WIRE LEFT REAR DOOR SPEAKER LEFT SUBWOOFER LEFT SURROUND SPEAKER NCA WIRE ORG/ WIRE PASSENGER DOOR MIDRANGE SPEAKER PASSENGER DOOR TWEETER SPEAKER PNK WIRE PWR RED WIRE RED/BLK WIRE RED/ORG WIRE RIGHT REAR DOOR SPEAKER RIGHT SURROUND SPEAKER WHT WIRE YEL WIRE

Go to component -> Navigation circuit, w/ active noise (7 of 9) -> BLK WIRE

blk wiring diagram (143 of 195)

ACC/ON INPUT (ISG) AMP BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR SPEAKER FL (-) FR (-) FR GND FRT LH MID/TWT (-) FRT RH MID/TWT (-) GRN WIRE GRY WIRE ISG B+ INPUT LEFT REAR DOOR MIDRANGE SPEAKER LEFT REAR DOOR TWEETER SPEAKER M-CAN HIGH M-CAN LOW MID MID (-) SUBWOOFER 1 (+) NAVI VOICE (+) NAVI VOICE (-) ON/START INPUT NCA WIRE ORG/ WIRE PASSENGER DOOR SPEAKER PNK WIRE RANC MIC HIGH RED WIRE RIGHT REAR DOOR MIDRANGE SPEAKER RIGHT REAR DOOR TWEETER SPEAKER RIGHT SUBWOOFER RL (+) RR (-) RR LH MID/TWT (+) RR LH MID/TWT (-) RR RH MID/TWT (+) RR RH MID/TWT (-) SPDIF HIGH SPDIF LOW SPDIF SHIELD SUBWOOFER 1 (-) SUBWOOFER 2 (-) SUBWOOFER 2 (-) RANC SENSOR LOW RANC SENSOR HIGH SURROUND LH (-) SURROUND RH (-) SURROUND RH (-) RANC MIC LOW TWT (-) WHT WIRE YEL WIRE

Go to component -> Navigation circuit, w/ active noise (9 of 9) -> BLK WIRE

blk wiring diagram (144 of 195)

ACC/ON B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DETENT FRONT CONSOLE USB CONNECTOR ASSEMBLY GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRY WIRE GRY/ORG WIRE ILL INPUT (ISG) LEFT PADDLE SHIFT (DOWN) SWITCH LEFT STEERING WHEEL REMOTE CONTROL SWITCH LT GRN WIRE MEMORY MEMORY PWR NCA WIRE ON/START INPUT ORG/ WIRE ORG/BLK WIRE PADDLE PNK WIRE POWER DISTRIBUTION SYSTEM PWR REAR CONSOLE USB CHARGER REAR SEAT CONSOLE REMOTE CONTROL SWITCH RED WIRE RED/ORG WIRE RIGHT PADDLE SHIFT (UP) SWITCH RIGHT STEERING WHEEL REMOTE CONTROL SWITCH S-CAN HIGH S-CAN LOW SHIFT DOWN SHIFT UP STEERING WHEEL) USB DATA-RX GND USB DATA-RX HIGH USB DATA-RX LOW USB DATA-TX GND USB DATA-TX HIGH USB DATA-TX LOW USB GND USB HSD HIGH USB HSD LOW USB VCC WHT WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE

Go to component -> Navigation circuit, w/ premium amplifier (4 of 8) -> BLK WIRE

blk wiring diagram (145 of 195)

'B' OUTPUT ACC/ON INPUT ACC/ON OUTPUT BLK WIRE BLK/ORG WIRE BLU/BLK WIRE BRN WIRE BRN/BLK WIRE CRASH DIAGNOSIS CIRCUIT ESU ETHERNET FRONT VIEW CAMERA GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRY/BLK WIRE GRY/ORG WIRE HOT W/ ACC RELAY ENERGIZED ICU JUNCTION BLOCK ICU WAKEUP ICU-D ICU-E ICU-I ICU-J ICU-K ICU-L IPS CONTROL MODULE LOW DC-DC CONVERTER (AMP) MATCHING CIRCUIT MODULE 6 FUSE NCA WIRE ORG/BLK WIRE PASSENGER POWER OUTSIDE MIRROR PNK WIRE PWR REAR VIEW CAMERA RED WIRE RED/BLK WIRE RED/ORG WIRE SW (OUTSIDE) SW GND TRUNK UNLOCK TRUNK, TAILGATE, FUEL DOORS SYSTEM UNLOCK WAKEUP SIG WHT/ORG WIRE YEL WIRE

Go to component -> Navigation circuit, w/ premium amplifier (6 of 8) -> BLK WIRE

blk wiring diagram (146 of 195)

A/V, NAVIGATION HEAD UNIT A/V, NAVIGATION KEYBOARD ACC/ON INPUT BACKUP LAMP SIG BLK WIRE BLK/ORG WIRE BLU WIRE COAXIAL CABLE COMPUTER DATA LINES SYSTEM FRONT MONITOR GROUND FRONT MONITOR PWR GRN WIRE GRN/ORG WIRE GROUND GRY WIRE HOT W/ HOT W/ SHORT TERM LOAD LATCH RELAY ENERGIZED ICU JUNCTION BLOCK ICU-A ICU-G ICU-H ILL KEYBOARD GROUND KEYBOARD PWR KEYBOARD RESET LEFT MIC LOCAL HS-CAN LOCAL HS-CAN HIGH LOCAL HS-CAN LOW MEMORY PWR MIC - MIC LH (+) MIC LH SHIELD MIC RH (+) MIC RH (-) MIC LH (-) MIC RH SHIELD MODULE 3 FUSE MODULE 9 FUSE ON/START INPUT ORG/BLK WIRE PNK WIRE RED WIRE RED/BLK WIRE RIGHT MIC SVM DETECT VIDEO SIG WHT WIRE WHT/ORG WIRE YEL WIRE

Go to component -> Navigation circuit, w/ standard amplifier (1 of 7) -> BLK WIRE

blk wiring diagram (147 of 195)

ACC/ON INPUT (ISG) AMP BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CENTER SPEAKER CENTER SPKR (-) COMPUTER DATA LINES SYSTEM DRIVER DOOR SPEAKER DRIVER DOOR TWEETER SPEAKER DRIVER POWER OUTSIDE MIRROR ETHERNET FRT LH MID/TWT (-) FRT RH MID/TWT (-) FRT RH MID/TWT (-) GROUND GRN WIRE GRN/BLK WIRE GROUND GRY/ORG WIRE ISG B+ INPUT LEFT REAR DOOR SPEAKER LEFT SUBWOOFER M-CAN HIGH M-CAN LOW NAVI VOICE (+) NAVI VOICE (-) ON/START INPUT NCA WIRE ORG/ WIRE ORG/BLK WIRE PASSENGER DOOR SPEAKER PASSENGER DOOR TWEETER SPEAKER PNK WIRE PWR RED WIRE RED/BLK WIRE RED/ORG WIRE RIGHT REAR DOOR SPEAKER RIGHT SUBWOOFER RL (+) RR (-) SPDIF HIGH SPDIF LOW SPDIF SHIELD SUBWOOFER 1 (-) SUBWOOFER 2 (-) WHT WIRE WHT/ORG WIRE YEL WIRE

Go to component -> Navigation circuit, w/ standard amplifier (7 of 7) -> BLK WIRE

blk wiring diagram (148 of 195)

8 INCH COLOR TFT LCD AMP B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE CLUSTER FUSE COMPUTER DATA LINES SYSTEM DAC DISPLAY FRONT CONSOLE SWITCH FRONT SENS SPLY PNK REAR SENS SPLY WIRE GCU GRN WIRE GROUND GRY WIRE GRY/BLK WIRE IBU (RIGHT SIDE OF DASH) ICU JUNCTION BLOCK ICU-G ICU-H ILL IND INSTRUMENT CLUSTER LEFT CENTER PARKING DISTANCE WARNING FORWARD SENSOR LEFT CENTER PARKING DISTANCE WARNING REVERSE SENSOR LEFT PARKING DISTANCE WARNING FORWARD SENSOR LEFT PARKING DISTANCE WARNING REVERSE SENSOR M-CAN TRANSCEIVER MICOM MODULE 7 FUSE ORG/ WIRE PDW SPLY INPUT PDW SW IND PDW SW SIG PDW SWITCH PNK WIRE POWER RED WIRE RIGHT CENTER PARKING DISTANCE WARNING FORWARD SENSOR RIGHT CENTER PARKING DISTANCE WARNING REVERSE SENSOR RIGHT PARKING DISTANCE WARNING FORWARD SENSOR RIGHT PARKING DISTANCE WARNING REVERSE SENSOR SIG 1 GND W/ 8 INCH TFT LCD DISPLAY WHT WIRE YEL WIRE

Go to component -> Parking assistant circuit -> BLK WIRE

blk wiring diagram (149 of 195)

8 INCH COLOR TFT LCD A/V, NAVIGATION HEAD UNIT ACC/ON INPUT ACC/ON INPUT (ISG) SVM SW SIG ACC/ON OUTPUT ADAS UNIT (PARKING) AMP BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CLUSTER FUSE COMPUTER DATA LINES SYSTEM DAC DISPLAY ETHERNET FRONT CONSOLE KEYBOARD FRONT CONSOLE SWITCH GCU GRN WIRE GRY WIRE HOT W/ ICU JUNCTION BLOCK ICU-H ILL INSTRUMENT CLUSTER LIN (PDW-F) LIN (PDW-R) LIN LH (SPAS) LIN RH (SPAS) PDW SUPPLY INPUT LOW DC-DC CONVERTER M-CAN TRANSCEIVER MICOM MODULE 11 FUSE MODULE 8 FUSE ON INPUT ON/START INPUT ORG/ WIRE PDW SW IND PDW SW SIG PDW SWITCH PNK ACC (ISG) WIRE PNK ACC/ON INPUT (ISG) WIRE PNK PNK WIRE PNK WIRE REAR CONSOLE USB CHARGER REAR SEAT CONSOLE REMOTE CONTROL SWITCH REAR SENS SPLY RED WIRE RED/BLK WIRE SIG 1 GND SVM SW SIG SVM SWITCH W/ 8 INCH TFT LCD DISPLAY WHT WIRE WHT/ORG WIRE YEL WIRE

Go to component -> Remote smart parking assist circuit (1 of 2) -> BLK WIRE

blk wiring diagram (150 of 195)

BLK WIRE BLK/ORG WIRE BLU WIRE BRN WIRE GRN WIRE LEFT CENTER PARKING DISTANCE WARNING FORWARD SENSOR LEFT CENTER PARKING DISTANCE WARNING REVERSE SENSOR LEFT PARKING DISTANCE WARNING FORWARD SENSOR LEFT PARKING DISTANCE WARNING REVERSE SENSOR LEFT SIDE PARKING DISTANCE WARNING FORWARD SENSOR LEFT SIDE PARKING DISTANCE WARNING REVERSE SENSOR LID 1 LID 2 LID 3 PWR RED WIRE RIGHT CENTER PARKING DISTANCE WARNING FORWARD SENSOR RIGHT CENTER PARKING DISTANCE WARNING REVERSE SENSOR RIGHT PARKING DISTANCE WARNING FORWARD SENSOR RIGHT PARKING DISTANCE WARNING REVERSE SENSOR RIGHT SIDE PARKING DISTANCE WARNING FORWARD SENSOR RIGHT SIDE PARKING DISTANCE WARNING REVERSE SENSOR

Go to component -> Remote smart parking assist circuit (2 of 2) -> BLK WIRE
