Genesis G80 II (2020-2024) awd ecu Wiring diagrams
This page contains all the electrical diagrams for the component. awd ecu, in which he is found in the car Genesis G80 II (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
awd ecu wiring diagram (1 of 4)
AWD ECU
B-CAN HIGH
B-CAN LOW
BLU WIRE
BLU/BLK WIRE
BRN WIRE
C-CAN
C-CAN HIGH
C-CAN LOW
CCP-CAN HIGH
CCP-CAN LOW
ELECTRONIC ATM SHIFT LEVER DIAL
GRN WIRE
GRN/ORG WIRE
IBU (RIGHT SIDE OF DASH)
IEB UNIT
MDPS UNIT
MULTI- FUNCTION SWITCH
ORG/ WIRE
P-CAN
P-CAN HIGH
P-CAN LOW
PASSENGER OCCUPANT DETECTION SENSOR
RED WIRE
RED/BLK WIRE
RIGHT END OF DASH)
SRS CONTROL MODULE
W/ RSW, ECS
W/O RSW, ECS
WHT WIRE
Go to component -> Computer data lines circuit (3 of 9) -> AWD ECU
awd ecu wiring diagram (2 of 4)
2.5L TURBO 3.5L TURBO
ACC RELAY
ACTIVE AIR FLAP MODULE
AWD ECU
BLK WIRE
COOLING FAN MOTOR
CRANKSHAFT POSITION SENSOR SHIELD
E/R SUB JUNCTION BLOCK BLOWER RELAY
E/R-A
ELECTRONIC OIL PUMP
ELECTRONIC WATER PUMP
HOOD SWITCH
HORN (HIGH)
HORN (LOW)
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
LEFT HEADLAMP
MAP SENSOR 2 SHIELD
MDPS UNIT
NCA WIRE
OIL LEVEL SENSOR
ORG/ WIRE
PCB BLOCK
RIGHT HEADLAMP
RIGHT SIDE DOWN REPEATER LAMP
SMART CRUISE CONTROL RADAR
TCM
TRANSMISSION PARK POSITION SENSOR/ SWITCH
WASHER LEVEL SENSOR
WASHER MOTOR
Go to component -> Ground distribution circuit (3 of 7) -> AWD ECU
awd ecu wiring diagram (3 of 4)
A/C FUSE
A/C RELAY
ALT FUSE
ALTERNATOR
AMS FUSE
AWD ECU
B+5 FUSE
B+6 FUSE
B+7 FUSE
B+8 FUSE
BAT-A
BAT-B
BAT-C
BATTERY
BATTERY SENSOR
BLK WIRE
BLOWER FUSE
BLOWER RELAY
BLU WIRE
COOLING FAN FUSE
COOLING FAN MOTOR
E-CVVT 1 FUSE
E-CVVT RELAY
E/R JUNCTION BLOCK
E/R-A
ECU 1 FUSE
ELECTRONIC OIL PUMP
FROM LOW DC-DC CONVERTER (DIAGRAM 8 OF 11)
GRN WIRE
GRY WIRE
HORN FUSE
HORN RELAY PCB BLOCK
IEB 1 FUSE
IEB 2 FUSE
IEB 3 FUSE
IEB UNIT
LDC FUSE
MDPS 1 FUSE
MDPS UNIT
MULTI FUSE
OIL PUMP FUSE
PNK WIRE
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
RWS FUSE
RWS MODULE
START MOTOR
TO LEFT HEADLAMP FUSE (DIAGRAM 3 OF 11)
TO REAR JUNCTION BLOCK (DIAGRAM 2 OF 11)
WHT WIRE
WIPER FUSE
WIPER MOTOR
Go to component -> Power distribution circuit (1 of 11) -> AWD ECU
awd ecu wiring diagram (4 of 4)
ACC FUSE
ACC RELAY
AWD ECU
BLK WIRE
BLU WIRE
BLU/ORG WIRE
E/R-A
ECU 2 FUSE
ECU 3 FUSE
ELECTRONIC OIL PUMP
ELECTRONIC WATER PUMP
ENGINE CONTROL RELAY
EWP FUSE
FROM ECU 1 FUSE (DIAGRAM 1 OF 11)
FUEL PUMP FUSE
FUEL PUMP RELAY
GRN WIRE
GRN/BLK WIRE
GRY WIRE
IBU
IEB 4 FUSE
IEB UNIT
LEFT FRONT RADAR
LEFT HEADLAMP
LEFT HEADLAMP FUSE
MDPS 2 FUSE
MDPS UNIT
MODULE 2 FUSE
NCA WIRE
ORG/ WIRE
P/N RELAY
PCB BLOCK
PNK WIRE
PNK/BLK WIRE
RED WIRE
RIGHT FRONT RADAR
RIGHT HEADLAMP
RIGHT HEADLAMP FUSE
SENSOR 5 FUSE
SMART CRUISE CONTROL RADAR
START FUSE
START RELAY
TCM
TCU 1 FUSE
TCU 2 FUSE
TO ICU JUNCTION BLOCK (DIAGRAM 5 OF 11)
TO ICU JUNCTION BLOCK (DIAGRAM 6 OF 11)
WASHER FUSE
WASHER RELAY
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 11) -> AWD ECU
