Genesis G80 II (2020-2024) auto defogger sens sda Wiring diagram
This page shows the only wiring diagram for the component.auto defogger sens sda, which is found in the car Genesis G80 II (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto defogger sens sda (1 of 1)
A/C CONTROL MODULE
AUTO DEFOGGER ACTUATOR
AUTO DEFOGGER ACTUATOR CLOSE
AUTO DEFOGGER ACTUATOR F/B
AUTO DEFOGGER ACTUATOR OPEN
AUTO DEFOGGER SENS GLASS TEMP
AUTO DEFOGGER SENS SCL
AUTO DEFOGGER SENS SDA
AUTO DEFOGGER SENSOR
BLK WIRE
BLU WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER
E-CAN HIGH
E-CAN LOW
E/R JUNCTION BLOCK
FRONT A/C CONTROLLER
GLASS TEMP
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
HTD IND FUSE
ICU JUNCTION BLOCK
ICU-C
ICU-E
IND
IPS CONTROL MODULE
LSD
MEM PWR
MULTI FUSE
NCA WIRE
OFF
ORG/ WIRE
PNK WIRE
REAR
REAR DEFOGGER
REAR DEFOGGER SWITCH
REAR HEATED FUSE
REAR HEATED RELAY
RED WIRE
RLY CTRL
SCL
SDA
SENS
SENS SPLY (+) SENS GND
SWITCH INPUT
WHT WIRE
YEL WIRE
Go to component -> Defoggers circuit (1 of 2) -> AUTO DEFOGGER SENS SDA
