Genesis G80 I (2016-2020) rear curtain motor gnd Wiring diagram
This page shows the only wiring diagram for the component.rear curtain motor gnd, which is found in the car Genesis G80 I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear curtain motor gnd (1 of 1)
B+1 FUSE
B-CAN HI
B-CAN LO
BCM
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
CRASH PAD SWITCH
E/R JUNCTION BLOCK
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
I/P-A
I/P-B
I/P-H
IGPM (INTEGRATED GATEWAY POWER CONTROL MODULE)
ILL
MEMORY POWER
MODULE 9 FUSE
MULTI FUSE
ORG/ WIRE
ORG/BLK WIRE
REAR CURTAIN MOTOR
REAR CURTAIN MOTOR DOWN
REAR CURTAIN MOTOR GND
REAR CURTAIN MOTOR PWR
REAR CURTAIN MOTOR UP
REAR CURTAIN SW
REAR CURTAIN SWITCH
REAR SEAT CONSOLE SWITCH
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
Go to component -> Rear curtain circuit -> REAR CURTAIN MOTOR GND
