Genesis G80 I (2016-2020) rcv control solenoid valve Wiring diagram
This page shows the only wiring diagram for the component.rcv control solenoid valve, which is found in the car Genesis G80 I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rcv control solenoid valve (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CKPS HIGH
CKPS LOW
CRANKSHAFT POSITION SENSOR
GRN WIRE
GRY WIRE
HIGH PRESSURE FUEL PUMP
IGNITION COIL CTRL CYL 2
IGNITION COIL CTRL CYL 3
IGNITION COIL CTRL CYL 6
INJECTOR CTRL 1 LOW
INJECTOR CTRL 4 LOW
INJECTOR CTRL 5 LOW
KNOCK SENS 1 HIGH
KNOCK SENS 1 LOW
KNOCK SENS 2 HIGH
KNOCK SENS 2 LOW
OIL CONTROL VALVE 3
OIL CONTROL VALVE 4
OIL PRESS SENS
OIL PRESSURE SOLENOID VALVE
OPSV CTRL
ORG/ WIRE
OXYGEN SENSOR 1 V G
OXYGEN SENSOR 1 V IP
OXYGEN SENSOR 1 V N
OXYGEN SENSOR 1 V RC
OXYGEN SENSOR 2 V G
OXYGEN SENSOR 2 V IP
OXYGEN SENSOR 2 V N
OXYGEN SENSOR 2 V RC
OXYGEN SENSOR 3 GND
OXYGEN SENSOR 3 HEATER
OXYGEN SENSOR 3 SIG
OXYGEN SENSOR 4 GND
OXYGEN SENSOR 4 HEATER
OXYGEN SENSOR 4 SIG
PNK WIRE
PNK/BLK WIRE
POSITION F/B SIG EWGA 1
RCV CONTROL SOLENOID VALVE
RCV CTRL
RED WIRE
RED/BLK WIRE
TPS 1 SIG
TPS GND
TPS SPLY
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.3l turbo (4 of 9) -> RCV CONTROL SOLENOID VALVE
