Genesis G80 I (2016-2020) org/ Wiring diagrams

This page contains all the electrical diagrams for the component. org/, in which he is found in the car Genesis G80 I (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

org/ wiring diagram (91 of 168)

5.0L B-CAN B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE C-CAN C-CAN HIGH C-CAN LOW D-CAN DATA LINK CONNECTOR DRIVER LUMBAR SUPPORT UNIT E/R JUNCTION BLOCK ELECTRIC PARKING BRAKE MODULE ESC 1 FUSE ESC 2 FUSE FRONT MONITOR (AVN HIGH) GATEWAY GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES HS CAN+ I/P-G I/P-I IGPM (INTEGRATED GATEWAY POWER CONTROL MODULE) M-CAN METAL CORE BLOCK 2 METAL CORE BLOCK MODULE 1 FUSE MULTIPURPOSE CHECK CONNECTOR NCA WIRE ORG/ WIRE P-CAN REAR JUNCTION BLOCK (RIGHT SIDE OF LUGGAGE COMPT) REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH RED WIRE RS-A SMART CRUISE CONTROL RADAR SMART KEY CONTROL MODULE (LEFT CENTER OF DASH) W/ EPB W/O AVM WHT WIRE

Go to component -> Computer data lines circuit (1 of 5) -> ORG/ WIRE

org/ wiring diagram (92 of 168)

A/V, NAVIGATION HEAD UNIT I-BOX AVN HIGH AVN STANDARD B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE C-CAN HIGH C-CAN LOW C-CAN PR HIGH C-CAN PR LOW DRIVER DOOR MODULE DRIVER IMS CONTROL MODULE DRIVER POWER OUTSIDE MIRROR DRIVER POWER SEAT SWITCH ECS UNIT ELECTRONIC ATM SHIFT LEVER GRN WIRE GRY WIRE GRY/BLK WIRE HS-CAN HIGH HS-CAN LOW LANE KEEPING ASSIST MODULE LEFT BLIND SPOT DETECTION RADAR LEFT REAR DOOR MODULE LIN M-CAN HIGH M-CAN LOW NCA WIRE ORG/ WIRE P-CAN HIGH P-CAN LOW PASSENGER DOOR MODULE POWER TRUNK LID CONTROL MODULE RED WIRE RIGHT BLIND SPOT DETECTION RADAR RIGHT REAR DOOR MODULE STEERING TILT, TELESCOPIC MODULE W/ LKAS W/O LKAS WHT WIRE

Go to component -> Computer data lines circuit (2 of 5) -> ORG/ WIRE

org/ wiring diagram (93 of 168)

3.8L, 3.3L TURBO 5.0L 5.0L 3.8L, 3.3L TURBO A/C CONTROL MODULE AUTO HEADLAMP LEVELING DEVICE MODULE B-CAN HIGH B-CAN LOW BCM BLU WIRE BLU/BLK WIRE BODY K-LINE BRN WIRE C-CAN HIGH C-CAN LOW CCP-CAN HIGH CCP-CAN LOW CLOCKSPRING FRONT POWER OUTLET, CIGARETTE LIGHTER FRONT WIRELESS CHARGER GRN WIRE HEAD-UP DISPLAY INSTRUMENT CLUSTER M-CAN HIGH M-CAN LOW MDPS UNIT MULTI- FUNCTION SWITCH NCA WIRE ORG/ WIRE P-CAN HIGH P-CAN LOW PNK WIRE PPL RED WIRE RIGHT END OF DASH) STEERING WHEEL CRUISE/ TRIP REMOTE CONTROL SWITCH W/ E-SHIFT W/O E-SHIFT WHT WIRE

Go to component -> Computer data lines circuit (3 of 5) -> ORG/ WIRE

org/ wiring diagram (94 of 168)

3.8L, 3.3L TURBO 5.0L 5.0L 3.8L, 3.3L TURBO AMP (W/ JBL) BLU WIRE BRN WIRE C-CAN HIGH C-CAN LOW M-CAN HIGH M-CAN LOW MULTI-VIEW CAMERA MODULE ORG/ WIRE P-CAN HIGH P-CAN LOW RED WIRE STEERING ANGLE SENSOR TCM TIRE PRESSURE MONITORING MODULE W/ AV W/O A/V, WHT WIRE

Go to component -> Computer data lines circuit (4 of 5) -> ORG/ WIRE

org/ wiring diagram (95 of 168)

ACTIVE AIR FLAP AVN HIGH AVN STANDARD BLU WIRE BRN WIRE C-CAN HIGH C-CAN LOW DIGITAL CLOCK ESC MODULE ESC UNIT FRONT MONITOR FUEL PUMP CONTROL MODULE KEY BOARD M-CAN HIGH M-CAN LOW NCA WIRE ORG/ WIRE P-CAN P-CAN HIGH P-CAN LOW PASSENGER WEIGHT CLASSIFICATION SENSOR PRE-ACTIVE SEAT BELT MODULE RED WIRE RIGHT END OF DASH) SRS CONTROL MODULE WHT WIRE

Go to component -> Computer data lines circuit (5 of 5) -> ORG/ WIRE

org/ wiring diagram (96 of 168)

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BODY G-SENS FL SIG BODY G-SENS FR SIG BODY G-SENS REAR SIG BRN WIRE BRN/BLK WIRE C-CAN C-CAN HIGH C-CAN LOW COMPUTER DATA LINES SYSTEM DAMPER GND ECS FUSE ECS UNIT ESC MODULE ESC UNIT FL SIG FL VCC FR SIG FR VCC GATEWAY GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GROUND GRY/BLK WIRE HIGH LOW HOT AT ALL TIMES I/P-E I/P-I IGPM (INTEGRATED GATEWAY POWER CONTROL MODULE) LEFT FRONT BODY ECS G-SENSOR LEFT FRONT WHEEL ECS G-SENSOR (ON LEFT FRONT HUB ASSEMBLY) LEFT REAR ECS SOLENOID VALVE MEMORY POWER MODULE 4 FUSE NCA WIRE ON/START INPUT ORG/ WIRE PNK WIRE REAR BODY ECS G-SENSOR REAR JUNCTION BLOCK RED WIRE RED/BLK WIRE RIGHT FRONT BODY ECS G-SENSOR RIGHT FRONT WHEEL ECS G-SENSOR (ON RIGHT FRONT HUB ASSEMBLY) RIGHT REAR ECS SOLENOID VALVE RL SIG RL VCC RR SIG RR VCC RS-A SENS GROUND SENS POWER SOLENOID SOLENOID VALVE WHEEL G-SENS FL SIG WHEEL G-SENS FR SIG WHEEL G-SENSOR WHEEL SENSOR WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE

Go to component -> Electronic suspension circuit -> ORG/ WIRE

org/ wiring diagram (97 of 168)

ACC/ON INPUT AUDIO SHIELD AUX, USB JACK B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE CHASSIS GROUND COMPUTER DATA LINES SYSTEM DET ELECTROCHROMIC MIRROR FRONT MONITOR GRN WIRE GROUND GRY WIRE GRY/BLK WIRE GRY/ORG WIRE HS-CAN HIGH HS-CAN LOW I-BOX ILL KEYPAD KEYPAD GROUND KEYPAD SIGNAL M GROUND M-CAN HIGH M-CAN LOW MEMORY POWER MIC IN - MIC SHIELD MICOM ON/OFF MOST CABLE MOZEN NCA WIRE ON/START INPUT ORG/ WIRE P-CAN HIGH P-CAN LOW PHONE PNK WIRE RED WIRE RED/BLK WIRE RED/ORG WIRE SIGNAL SOS USB D (+)/IPOD RX USB D-/IPOD TX USB/IPOD GROUND USB/IPOD VCC W/ E-SHIFT W/O E-SHIFT WHT WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE

Go to component -> Navigation circuit, avn high w/o jbl (2 of 5) -> ORG/ WIRE

org/ wiring diagram (98 of 168)

ANT-CG ANT-S ANT-SC AUDIO SW OUT AUDIO/BLUETOOTH REMOTE CONTROL SWITCH B-CAN HIGH B-CAN LOW BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE BPF BRN WIRE CANADA CDMA/LTE CLOCKSPRING COMBINATION ANTENNA COMPUTER DATA LINES SYSTEM CRUISE/TRIP REMOTE CONTROL SWITCH DIAGNOSIS CIRCUIT ENCODER GPS GRN WIRE GROUND GRY WIRE GRY/ORG WIRE HOT AT ALL TIMES I/P-H IGPM (INTEGRATED GATEWAY POWER CONTROL MODULE) ILL (+) IN ILL (-) OUT INSTRUMENT CLUSTER IPS 1 CONTROL IPS CONTROL MODULE LDO LNA LT BLU WIRE MATCHING CIRCUIT MEMORY POWER NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RED/BLK WIRE STEERING WHEEL) SXM TRIP SW GROUND TRIP SW SIG USA VIO WIRE WHT WIRE WHT/ORG WIRE WHT/RED WIRE YEL WIRE

Go to component -> Navigation circuit, avn standard w/ jbl (4 of 6) -> ORG/ WIRE

org/ wiring diagram (99 of 168)

ACC/ON INPUT AMP AMP FUSE BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR SPEAKER DRIVER DR SPKR (-) DRIVER TW SPKR (-) GRN WIRE GRN/BLK WIRE GROUND GRY/ORG WIRE HOT AT ALL TIMES LEFT REAR DOOR SPEAKER LEFT REAR SPKR (-) M-CAN HIGH M-CAN LOW MEMORY POWER MOST CABLE MOST CABLE MOST-AMP NAVI VOICE (+) NAVI VOICE (-) ON/START INPUT NCA WIRE ORG/ WIRE ORG/BLK WIRE PASSENGER DOOR SPEAKER PASSENGER DR SPKR (+) PASSENGER DR SPKR (-) GROUND PASSENGER TW SPKR (-) PASSENGER TWEETER SPEAKER PNK WIRE REAR JUNCTION BLOCK RED WIRE RED/BLK WIRE RIGHT REAR DOOR SPEAKER RIGHT REAR SPKR (-) RS-A SPDIF (-) SPDIF (-) SPDIF GROUND SUB W/ SPKR 1 (-) SUB W/ SPKR 2 (-) WHT WIRE WHT/ORG WIRE WOOFER SPEAKER YEL WIRE

Go to component -> Navigation circuit, avn standard w/o jbl (5 of 5) -> ORG/ WIRE

org/ wiring diagram (100 of 168)

B-CAN HIGH B-CAN LOW BCM BLK WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE C-CAN C-CAN HIGH C-CAN LOW CLUSTER FUSE COMPUTER DATA LINES SYSTEM CONTROL CRASH PAD SWITCH DOOR OPEN IND F/LID FUSE FUEL FILLER ACTUATOR FUEL LID OPEN RELAY FUEL LID OPEN SWITCH GATEWAY GRN WIRE GRN/ORG WIRE GROUND GRY WIRE HOT AT ALL TIMES I/P-E I/P-G I/P-H I/P-I IGPM (INTEGRATED GATEWAY POWER CONTROL MODULE) INSTRUMENT CLUSTER IPS CONTROL MODULE LATCH) LEAK CURRENT AUTO CUT DEVICE LOCK STATUS MCU MCU 1 MEMORY 1 FUSE MEMORY POWER MOTOR NCA WIRE ON/START INPUT ORG/ WIRE ORG/BLK WIRE POWER REAR JUNCTION BLOCK RED/BLK WIRE RED/ORG WIRE RELAY RELAY ENERGIZED RS-A SUPPLY SWITCH TRANSCEIVER/ TRUNK TRUNK FUSE TRUNK LATCH MOTOR TRUNK LID TRUNK LID HANDLE SWITCH TRUNK LID MAIN SWITCH TRUNK LID RELAY TRUNK OPEN IND TRUNK OPEN SWITCH W/ 4.2 INCH TFT LCD WHT WIRE

Go to component -> Trunk & fuel door release circuit -> ORG/ WIRE
