Genesis G80 I (2016-2020) open alarm Wiring diagram
This page shows the only wiring diagram for the component.open alarm, which is found in the car Genesis G80 I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram open alarm (1 of 1)
BCM
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CLOSE
CLOSE/ TILT DOWN TILT UP
CRUISE CONTROL SYSTEM
GND SIG A
GRN WIRE
GRN/BLK WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
I/P-F
I/P-G
IGPM (INTEGRATED GATEWAY POWER CONTROL MODULE)
ILL
MEMORY PWR
MODULE 7 FUSE
ON INPUT
OPEN ALARM
ORG/ WIRE
OVERHEAD CONSOLE LAMP
SIG A
SIG B
SIG C
SUNROOF FUSE
SUNROOF MOTOR (FRONT OF SUNROOF)
SUNROOF STATUS
SUNROOF SWITCH
TILT
VEHICLE SPEED
YEL WIRE
Go to component -> Power top/sunroof circuit -> OPEN ALARM
