Genesis G80 I (2016-2020) metal core block 2 metal core block Wiring diagram
This page shows the only wiring diagram for the component.metal core block 2 metal core block, which is found in the car Genesis G80 I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram metal core block 2 metal core block (1 of 1)
5.0L
B-CAN
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN
C-CAN HIGH
C-CAN LOW
D-CAN
DATA LINK CONNECTOR
DRIVER LUMBAR SUPPORT UNIT
E/R JUNCTION BLOCK
ELECTRIC PARKING BRAKE MODULE
ESC 1 FUSE
ESC 2 FUSE
FRONT MONITOR (AVN HIGH)
GATEWAY
GRN WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
HS CAN+
I/P-G
I/P-I
IGPM (INTEGRATED GATEWAY POWER CONTROL MODULE)
M-CAN
METAL CORE BLOCK 2 METAL CORE BLOCK
MODULE 1 FUSE
MULTIPURPOSE CHECK CONNECTOR
NCA WIRE
ORG/ WIRE
P-CAN
REAR JUNCTION BLOCK (RIGHT SIDE OF LUGGAGE COMPT)
REAR VIEW CAMERA, TRUNK LID HANDLE SWITCH
RED WIRE
RS-A
SMART CRUISE CONTROL RADAR
SMART KEY CONTROL MODULE (LEFT CENTER OF DASH)
W/ EPB
W/O AVM
WHT WIRE
Go to component -> Computer data lines circuit (1 of 5) -> METAL CORE BLOCK 2 METAL CORE BLOCK
