Genesis G80 I (2016-2020) leak current pwr auto cut relay gnd control Wiring diagram
This page shows the only wiring diagram for the component.leak current pwr auto cut relay gnd control, which is found in the car Genesis G80 I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram leak current pwr auto cut relay gnd control (1 of 1)
+VP
B+1 FUSE
BLK WIRE
BLU WIRE
CONTROL IC
CTRL L IND
DRIVER FOOT LAMP
E/R JUNCTION BLOCK
GRN WIRE
GRN/ORG WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
I/P-A
I/P-B
I/P-E
I/P-F
I/P-H
IGPM (INTEGRATED GATEWAY POWER CONTROL MODULE)
INTERIOR LAMP FUSE
IPS CONTROL MODULE
LAMP
LEAK CURRENT AUTO CUT RELAY
LEAK CURRENT PWR AUTO CUT RELAY GND CONTROL
LEFT FRONT VANITY LAMP
LEFT FRONT VANITY LAMP SWITCH
LEFT TRUNK ROOM LAMP
LIN
MCU
MEMORY POWER
MOOD LAMP RIGHT REAR INSIDE HANDLE LAMP
MULTI FUSE
NCA WIRE
PASSENGER FOOT LAMP
PNK WIRE
PNK/BLK WIRE
RED WIRE
REGULATOR
RIGHT FRONT VANITY LAMP
RIGHT FRONT VANITY LAMP SWITCH
RIGHT REAR DOOR
RIGHT REAR DOOR LAMP 1
RIGHT REAR DOOR LAMP 2
RIGHT REAR DOOR MODULE
RIGHT TRUNK ROOM LAMP
SYBOL
TRANSCEIVER IC
TRUNK ROOM LAMP
VBATT
WHT WIRE
YEL/BLK WIRE
Go to component -> Courtesy lamps circuit (4 of 5) -> LEAK CURRENT PWR AUTO CUT RELAY GND CONTROL
