Genesis G80 I (2016-2020) driver mode actuator def Wiring diagram

A/C CONTROL MODULE A/CON 2 FUSE AUTO DEFOGGER ACTUATOR CLOSE AUTO DEFOGGER ACTUATOR F/B AUTO DEFOGGER ACTUATOR OPEN BLK WIRE BLOWER FUSE BLOWER MOTOR BLOWER MOTOR (+) FET GATE BLOWER RELAY BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BRN WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM DETENT DRIVER MODE ACTUATOR DEF DRIVER MODE ACTUATOR F/B DRIVER MODE ACTUATOR VENT DRIVER TEMPERATURE ACTUATOR COOL DRIVER TEMPERATURE ACTUATOR F/B DRIVER TEMPERATURE ACTUATOR WARM ECV (+) ELECTRICAL CONTROL VALVE ELECTRONIC A/C COMPRESSOR FET (FIELD EFFECT TRANSISTOR) FET DRAIN GRN WIRE GRN/ORG WIRE GROUND GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES ILL (+) SENSOR POWER ILL (-) ON INPUT INTAKE ACTUATOR F/B INTAKE ACTUATOR FRE INTAKE ACTUATOR REC K LINE MCB-B METAL CORE BLOCK METAL CORE BLOCK 1 NCA WIRE ORG/ WIRE ORG/BLK WIRE P-CAN HIGH P-CAN LOW PASSENGER MODE ACTUATOR DEF PASSENGER MODE ACTUATOR F/B PASSENGER MODE ACTUATOR VENT PASSENGER TEMPERATURE ACTUATOR COOL PASSENGER TEMPERATURE ACTUATOR F/B PASSENGER TEMPERATURE ACTUATOR WARM PNK WIRE PNK/BLK WIRE RED WIRE WHT WIRE YEL WIRE YEL/ORG WIRE
