Genesis G80 I (2016-2020) air bag relay rear junction block Wiring diagram
This page shows the only wiring diagram for the component.air bag relay rear junction block, which is found in the car Genesis G80 I (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air bag relay rear junction block (1 of 1)
3.3L TURBO
3.8L, 3.3L TURBO
5.0L
ACTIVE AIR FLAP
AIR BAG RELAY REAR JUNCTION BLOCK
ARM REST POWER OUTLET 1
B/UP LAMP RELAY
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE BOOST VACUUM PRESSURE SENSOR SWITCH
BRN WIRE
ECU 2 FUSE
ESC 3 FUSE
ESC MODULE
FROM IGPM (INTEGRATED GATEWAY POWER CONTROL MODULE) (DIAGRAM 6 OF 13)
FROM METAL CORE BLOCK 1 (DIAGRAM 6 OF 13)
FROM START FUSE (DIAGRAM 1 OF 13)
FRONT POWER OUTLET, CIGARETTE LIGHTER
GRY WIRE
IG 1 FUSE
ILL
LEFT FRONT POWER OUTLET
MCB-H
MCB-I
MCB-J
MCB-K
MDPS 2 FUSE
MDPS UNIT
METAL CORE BLOCK
METAL CORE BLOCK 2
MODULE 3 FUSE
MULTIPURPOSE CHECK CONNECTOR
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
P/N RELAY
PNK WIRE
PNK/BLK WIRE
PWR
RED WIRE
RIGHT FRONT POWER OUTLET
RS-A
SENSOR 5 FUSE
SMART CRUISE CONTROL RADAR
SMART KEY CONTROL MODULE
STEERING ANGLE SENSOR
TCM
TCU 1 FUSE
TCU 2 FUSE
TO IGPM (INTEGRATED GATEWAY POWER CONTROL MODULE) (DIAGRAM 3 OF 13)
TRANSMISSION RANGE SWITCH
USB CHARGER
W/ E-SHIFT
W/O E-SHIFT
WHT WIRE
Go to component -> Power distribution circuit (12 of 13) -> AIR BAG RELAY REAR JUNCTION BLOCK
