Genesis G70 I facelift (2020-2024) washer motor sw power Wiring diagram

This page shows the only wiring diagram for the component.washer motor sw power, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram washer motor sw power (1 of 1)

Wiring diagram washer motor sw power for Genesis G70 I facelift (2020-2024)

Get access

2.0L TURBO 3.3L TURBO BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE E/R JUNCTION BLOCK E/R-D E/R-E FRONT WASHER SWITCH FRONT WIPER (LOW) RELAY FRONT WIPER HIGH RELAY FRONT WIPER LOW BACKUP SIG GND (BCM) GRN WIRE HOT AT ALL TIMES INT/VOL SW SIG MIST MULTI- FUNCTION SWITCH ON INPUT ORG/ WIRE PARKING SWITCH PCB BLOCK POSITION RED WIRE RIGHT END OF DASH) VOL 1 (FAST) VOL 2 VOL 3 VOL 4 VOL 5 (SLOW) WASHER MOTOR SW POWER WHT WIRE WIPER 'P' WIPER 1 FUSE WIPER 2 FUSE WIPER LOW SWITCH WIPER MOTOR WIPER POWER RELAY WIPER SW SIG YEL WIRE

Go to component: -> Front wiper/washer circuit (2 of 2) -> WASHER MOTOR SW POWER
