Genesis G70 I facelift (2020-2024) variable charge motion actuator Wiring diagram
This page shows the only wiring diagram for the component.variable charge motion actuator, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram variable charge motion actuator (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CAMSHAFT POSITION SENSOR 1 (INTAKE)
CAMSHAFT POSITION SENSOR 2 (EXHAUST)
CMPS (EXHAUST) SIG
CMPS (INTAKE) GND
CMPS (INTAKE) SIG
CRANKSHAFT POSITION SENSOR
E-CVVT MTR (-)
E-CVVT RLY ON INPUT
ELECTRIC WASTEGATE ACTUATOR
ETC MTR OUTPUT (-)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
MAP SENSOR 1
MAP SENSOR 2
ORG/BLK WIRE
OXYGEN SENS UP V-G
OXYGEN SENS UP V-IP
OXYGEN SENS UP V-N
OXYGEN SENS UP V-RC
PNK WIRE
PNK/BLK WIRE
RED WIRE
SENS FEEDBACK
SENS GND
SENS INTERFACE
SENS SIG
SENS SPLY
SHIELD GND
TPS 1 SIG
TPS 2 SIG
TPS GND
TPS SPLY
VARIABLE CHARGE MOTION ACTUATOR
WHT WIRE
YEL WIRE
Go to component: -> Wiring diagram engine performance 2.0l turbo, engine controls circuit (3 of 7) -> VARIABLE CHARGE MOTION ACTUATOR
