Genesis G70 I facelift (2020-2024) steering wheel steering wheel heated module Wiring diagram
This page shows the only wiring diagram for the component.steering wheel steering wheel heated module, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering wheel steering wheel heated module (1 of 1)
3.3L TURBO
BLE UNIT (BLUETOOTH LOW ENERGY)
BLK WIRE
BLK/ORG WIRE
BRAKE FLUID LEVEL SENSOR
CENTER ROOM LAMP
CLOCKSPRING
DATA LINK CONNECTOR
ELECTRIC WASTEGATE ACTUATOR 1 (SENSOR SHIELD)
ELECTRO- CHROMIC MIRROR
ETC MOTOR, THROTTLE POSITION SENSOR SHIELD
EXTERNAL BUZZER
FET (FIELD EFFECT TRANSISTOR)
FRONT POWER OUTLET
FRONT TRAY USB CHARGER
FRONT USB CHARGER
FRONT WIRELESS CHARGER
FRONT WIRELESS CHARGER INDICATOR
HEAD-UP DISPLAY
IAU (IDENTITY AUTHENTICATION UNIT)
IBU
IGNITION LOCK, CLUTCH SWITCH
LEFT FRONT WHEEL ECS G-SENSOR
LEFT HEADLAMP
LEFT VANITY LAMP
M/T
M/T, W/ SMART KEY
MULTI- FUNCTION SWITCH
MULTI-FUNCTION CAMERA UNIT
NCA WIRE
OVERHEAD CONSOLE LAMP
RAIN SENSOR
REAR USB CHARGER
RIGHT END OF DASH)
RIGHT FRONT WHEEL ECS G-SENSOR
RIGHT VANITY LAMP
ROOM LAMP
SMART CRUISE CONTROL MODULE
START/STOP BUTTON SWITCH
STEERING TILT, TELESCOPIC MODULE
STEERING TILT, TELESCOPIC SWITCH
STEERING WHEEL STEERING WHEEL HEATED MODULE
STOP LAMP SWITCH
WIPER MOTOR
Go to component: -> Ground distribution circuit (2 of 6) -> STEERING WHEEL STEERING WHEEL HEATED MODULE
