Genesis G70 I facelift (2020-2024) sig c Wiring diagram
This page shows the only wiring diagram for the component.sig c, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sig c (1 of 1)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CLOSE
CRUISE CONTROL SYSTEM
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
IBU
ICU ENABLE
ICU JUNCTION BLOCK
ICU-A
ICU-G
IPS CONTROL MODULE
LIN-COMM
MEMORY POWER
NCA WIRE
OPEN WARNING ALARM
ORG/ WIRE
OVERHEAD CONSOLE LAMP
PNK WIRE
POWER WINDOWS SYSTEM
PPL
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RED/WHT WIRE
SENS HALL 1
SENS HALL 2
SENS MTR HALL POWER SUPPLY
SENS MTR RLY CTRL CCW
SENS MTR RLY CTRL CW
SIG A
SIG B
SIG C
SIG-D
SUNROOF ASSEMBLY
SUNROOF CONTROL UNIT (GLASS)
SUNROOF CONTROL UNIT (ROLLER)
SUNROOF FUSE
SUNROOF STATUS IN
SUNROOF SWITCH
TILT UP
VEHICLE SPEED SIG
WHT WIRE
WINDOW SUNROOF ENABLE
YEL WIRE
Go to component: -> Power top/sunroof circuit -> SIG C
