Genesis G70 I facelift (2020-2024) right glass antenna Wiring diagrams

This page contains all the electrical diagrams for the component. right glass antenna, in which he is found in the car Genesis G70 I facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram right glass antenna (1 of 6)

Wiring diagram right glass antenna for Genesis G70 I facelift (2020-2024)

Get access

ACC/ON I/P ACC/ON O/P AM/FM AM/FM ANTENNA ANT B+ ANT-G BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BPF BRN WIRE BRN/BLK WIRE CIRCUIT COMBINATION ANTENNA DIAGNOSIS CIRCUIT DTC ELECTROCHROMIC MIRROR GNSS ANTENNA GNSS OUT/VIN GRN/WHT WIRE GRY/BLK WIRE ILL ISG SIGNAL IN KEYPAD L ISG SIG LDO LDO MATCHING CIRCUIT LNA LOW DC-DC CONVERTER (AMP) (W/ ISG) (LUGGAGE COMPT, NEXT TO BATTERY) LOW DC-DC CONVERTER (AUDIO) (W/ ISG) (RIGHT SIDE OF DASH) LTE ANTENNA MATCHING CIRCUIT MEMORY PWR I/P MEMORY PWR O/P NCA WIRE ON/START I/P ORG/ WIRE RED WIRE RED/BLK WIRE RIGHT GLASS ANTENNA START RELAY LDC SXM ANTENNA SXM OUT/VIN USB D- USB GND USB JACK USB VCC W/ ISG W/O ISG YEL WIRE YEL/ORG WIRE

Go to component: -> Navigation circuit, w/ amplifier & mid range (2 of 4) -> RIGHT GLASS ANTENNA

Wiring diagram right glass antenna (2 of 6)

Wiring diagram right glass antenna for Genesis G70 I facelift (2020-2024)

Get access

ACC/ON I/P ACC/ON O/P AM/FM AM/FM ANTENNA ANT B+ ANT-G BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BPF BRN WIRE CIRCUIT COMBINATION ANTENNA DIAGNOSIS CIRCUIT DTC GNSS ANTENNA GNSS OUT/VIN GRN/WHT WIRE ILL ISG SIGNAL I/P L ISG SIG LDO LDO MATCHING CIRCUIT LNA LOW DC-DC CONVERTER (AMP) (W/ ISG) (LUGGAGE COMPT, NEXT TO BATTERY) LOW DC-DC CONVERTER (AUDIO) (W/ ISG) (RIGHT SIDE OF DASH) LTE ANTENNA MATCHING CIRCUIT MEM PWR O/P MEMORY PWR I/P MEMORY PWR O/P NCA WIRE ON/START I/P ORG/ WIRE RED WIRE RED/BLK WIRE RIGHT GLASS ANTENNA START RELAY LDC SXM ANTENNA SXM OUT/VIN USB D- USB GND USB JACK USB VCC W/ ISG W/O ISG YEL WIRE YEL/ORG WIRE

Go to component: -> Navigation circuit, w/ amplifier w/o mid range (2 of 4) -> RIGHT GLASS ANTENNA

Wiring diagram right glass antenna (3 of 6)

Wiring diagram right glass antenna for Genesis G70 I facelift (2020-2024)

Get access

ACC/ON I/P ACC/ON O/P AM/FM AM/FM ANTENNA ANT B+ ANT-G BLK WIRE BLU WIRE BLU/ORG WIRE BPF BRN WIRE BRN/BLK WIRE CIRCUIT COMBINATION ANTENNA DIAGNOSIS CIRCUIT ELECTROCHROMIC MIRROR GNSS ANTENNA GNSS OUT/VIN GRN/WHT WIRE GRY/BLK WIRE KEYPAD L ISG SIG LDO LDO MATCHING CIRCUIT LNA LOW DC-DC CONVERTER (AUDIO) (W/ ISG) (RIGHT SIDE OF DASH) LTE ANTENNA MATCHING CIRCUIT MEMORY PWR I/P MEMORY PWR O/P NCA WIRE ON/START I/P ORG/ WIRE RED/BLK WIRE RIGHT GLASS ANTENNA RIGHT REAR DOOR SPEAKER START RELAY LDC SXM ANTENNA SXM OUT/VIN WHT WIRE

Go to component: -> Navigation circuit, w/o amplifier (2 of 3) -> RIGHT GLASS ANTENNA

Wiring diagram right glass antenna (4 of 6)

Wiring diagram right glass antenna for Genesis G70 I facelift (2020-2024)

Get access

ACC/ON I/P ACC/ON O/P AM/FM AM/FM ANTENNA ANT B+ ANT-G BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BPF BRN WIRE BRN/BLK WIRE CIRCUIT COMBINATION ANTENNA DIAGNOSIS CIRCUIT DTC ELECTROCHROMIC MIRROR GNSS ANTENNA GNSS OUT/VIN GRN/WHT WIRE GRY/BLK WIRE ILL ISG SIGNAL IN KEYPAD L ISG SIG LDO LDO MATCHING CIRCUIT LNA LOW DC-DC CONVERTER (AMP) (W/ ISG) (LUGGAGE COMPT, NEXT TO BATTERY) LOW DC-DC CONVERTER (AUDIO) (W/ ISG) (RIGHT SIDE OF DASH) LTE ANTENNA MATCHING CIRCUIT MEMORY PWR I/P MEMORY PWR O/P NCA WIRE ON/START I/P ORG/ WIRE RED WIRE RED/BLK WIRE RIGHT GLASS ANTENNA START RELAY LDC SXM ANTENNA SXM OUT/VIN USB D- USB GND USB JACK USB VCC W/ ISG W/O ISG YEL WIRE YEL/ORG WIRE

Go to component: -> Radio circuit, w/ amplifier & mid range (2 of 4) -> RIGHT GLASS ANTENNA

Wiring diagram right glass antenna (5 of 6)

Wiring diagram right glass antenna for Genesis G70 I facelift (2020-2024)

Get access

ACC/ON I/P ACC/ON O/P AM/FM AM/FM ANTENNA ANT B+ ANT-G BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BPF BRN WIRE CIRCUIT COMBINATION ANTENNA DIAGNOSIS CIRCUIT DTC GNSS ANTENNA GNSS OUT/VIN GRN/WHT WIRE ILL ISG SIGNAL I/P L ISG SIG LDO LDO MATCHING CIRCUIT LNA LOW DC-DC CONVERTER (AMP) (W/ ISG) (LUGGAGE COMPT, NEXT TO BATTERY) LOW DC-DC CONVERTER (AUDIO) (W/ ISG) (RIGHT SIDE OF DASH) LTE ANTENNA MATCHING CIRCUIT MEM PWR O/P MEMORY PWR I/P MEMORY PWR O/P NCA WIRE ON/START I/P ORG/ WIRE RED WIRE RED/BLK WIRE RIGHT GLASS ANTENNA START RELAY LDC SXM ANTENNA SXM OUT/VIN USB D- USB GND USB JACK USB VCC W/ ISG W/O ISG YEL WIRE YEL/ORG WIRE

Go to component: -> Radio circuit, w/ amplifier w/o mid range (2 of 4) -> RIGHT GLASS ANTENNA

Wiring diagram right glass antenna (6 of 6)

Wiring diagram right glass antenna for Genesis G70 I facelift (2020-2024)

Get access

ACC/ON I/P ACC/ON O/P AM/FM AM/FM ANTENNA ANT B+ ANT-G BLK WIRE BLU WIRE BLU/ORG WIRE BPF BRN WIRE BRN/BLK WIRE CIRCUIT COMBINATION ANTENNA DIAGNOSIS CIRCUIT ELECTROCHROMIC MIRROR GNSS ANTENNA GNSS OUT/VIN GRN/WHT WIRE GRY/BLK WIRE KEYPAD L ISG SIG LDO LDO MATCHING CIRCUIT LNA LOW DC-DC CONVERTER (AUDIO) (W/ ISG) (RIGHT SIDE OF DASH) LTE ANTENNA MATCHING CIRCUIT MEMORY PWR I/P MEMORY PWR O/P NCA WIRE ON/START I/P ORG/ WIRE RED/BLK WIRE RIGHT GLASS ANTENNA RIGHT REAR DOOR SPEAKER START RELAY LDC SXM ANTENNA SXM OUT/VIN WHT WIRE

Go to component: -> Radio circuit, w/o amplifier (2 of 3) -> RIGHT GLASS ANTENNA
