Genesis G70 I facelift (2020-2024) rh blower pwr b+ Wiring diagram
This page shows the only wiring diagram for the component.rh blower pwr b+, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rh blower pwr b+ (1 of 1)
B-CAN HIGH
B-CAN LOW
BACK B+
BACK HEATER
BLK WIRE
BLU WIRE
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
CUSH B+
CUSHION HEATER
FRONT AIR VENTILATION SEAT CONTROL MODULE
GRN WIRE
GRY WIRE
HEATER GND
HOT AT ALL TIMES
HOT IN ON OR START
ICU JUNCTION BLOCK
ICU-A
ICU-D
ICU-G
LEFT FRONT AIR VENTILATION SEAT WARMER
LH BACK B+
LH BLOWER PWR B+
LH CUSHION B+
LH HTR GND
LH NTC (+)
LH/RH NTC (-)
MEMORY POWER
MODULE 5 FUSE
NCA WIRE
NTC-
ON/START I/P LH BLOWER SPD CTRL
ORG/ WIRE
PNK WIRE
PWR GND
RED WIRE
RH BACK B+
RH BLOWER PWR B+
RH BLOWER SPD CTRL
RH CUSHION B+
RH HTR GND
RH NTC (+)
RIGHT FRONT AIR VENTILATION SEAT WARMER
S/HEATER DRV/PASS FUSE
WHT WIRE
YEL WIRE
Go to component: -> Seat ventilation circuit (1 of 2) -> RH BLOWER PWR B+
