Genesis G70 I facelift (2020-2024) power control module Wiring diagram

This page shows the only wiring diagram for the component.power control module, which is found in the car Genesis G70 I facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram power control module (1 of 1)

Wiring diagram power control module for Genesis G70 I facelift (2020-2024)

Get access

2.0L TURBO 3.3L TURBO B-CAN HIGH B-CAN LOW BLU WIRE BRN WIRE C-CAN HIGH C-CAN LOW CCP-CAN HIGH CCP-CAN LOW ECS UNIT FUEL PUMP CONTROL MODULE GRN WIRE GRY WIRE LEFT BLIND-SPOT COLLISION WARNING UNIT NCA WIRE ORG/ WIRE P-CAN HIGH P-CAN LOW PASSENGER OCCUPANT DETECTION SENSOR PNK WIRE POWER CONTROL MODULE REAR VIEW CAMERA RIGHT BLIND-SPOT COLLISION WARNING UNIT W/O SVM WHT WIRE YEL WIRE

Go to component: -> Computer data lines circuit (4 of 5) -> POWER CONTROL MODULE
